Huawei rectifier module R4830G1
| Price: | US$ 88 / Piece |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | T/T |
| Port of Export: | ShenZhen |
Product Details
| Model No.: | R4830G1 | Brand Name: | Huawei |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Huawei rectifier module R4830G1 Huawei R4830G1 Rectifier is a digital rectifier converting the 85~300VAC to 53.5 VDC and this module features high efficiency, high power density, walk-in start, hot-plug, complete protection, and low noise. The rectifier adopts the latest power monitoring technology and implements the function of monitoring the states of loads and the rectifier status in real-time. The output voltage of the rectifier can be adjusted through the host. |
Packaging & Delivery
| Packaging: | 1 pc/ctn |
|---|---|
| Delivery/Lead Time: | 6 |
| Production Capacity: | 666 |
Product Description
Huawei rectifier module R4830G1 Huawei R4830G1 Rectifier Product Features
Hot-plug
Digital control
Intelligent electric meter
Communication over CAN
Meet RoHS requirements
High efficiency: ≥96％
Input voltage range: 85~300VAC
Operating temperature range: -40℃~75℃
Total harmonic distortion(THD): ≤5％
Passing the TUV, CE, CB, UL certifications
Adjustment of voltage and current
Item: Specifications
Brand: Huawei
Model: R4830G1
Input
Input voltage: 85~300VAC
Input voltage mode: 220VAC single-phase (or 110VAC dual live lines)
Frequency: 45~65Hz
Rated: 50Hz/60Hz
Maximum input current: ≤13A
Power factor: ≥0.99
THD: ≤5％
Output
Output voltage: 42~58VDC
Default value: 53.5VDC
Output power: 1600W(176~300VAC)
Others
Dimension: 40.8(H)×95.5(W)×208(D)mm
Weight: ≤1.5kg
Cooling Forced air cooling
Environmental Specifications
Operating temperature: -40℃~+75℃(non-derating under 55℃)
Storage temperature: -40℃~+70℃
Relative humidity: 5%~95%(non-condensing)
Huawei R4830G1 Rectifier and More Related Power Rectifier
Part Number Input Voltage Output Voltage Output Power Efficiency Operating Temperature
R4805G1 85-300Vac 42-58Vdc 270W 94 % -40C to +75C
R4815G1 85-300Vac 42-58Vdc 870W 96 % -40C to +75C
R4815N1 85-300Vac 42-58Vdc 1000W 94 % -40C to +75C
R4830G1 85-300Vac 42-58Vdc 1600W 96 % -40C to +75C
R4830G2 85-300Vac 42-58Vdc 2000W 96 % -40C to +75C
R4830N2 85-300Vac 42-58Vdc 1605W 94 % -40C to +75C
R4850G1 85-300Vac 42-58Vdc 3000W 96 % -40C to +75C
R4850G2 85-300Vac 42-58Vdc 3000W 96 % -40C to +75C
R4850N1 85-300Vac 42-58Vdc 2900W 92 % -40C to +75C
R4850N2 85-300Vac 42-58Vdc 3000W 94 % -40C to +75C
R48100G1 260-530Vac 42-58Vdc 6000W 96 % -40C to +75C
R33640G1 260-530Vac 300-400Vdc 15kW 97% -40C to +75C
R50030G1 260-456Vac 300-500Vdc 15kW 95.8% -30C to +65C
|
