Huawei rectifier module R4815G1
| Price: | US$ 88 / Piece |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | T/T |
| Port of Export: | ShenZhen |
Product Details
| Model No.: | R4815G1 | Brand Name: | Huawei |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Huawei R4815g1 48V 15A 870W Rectifier Module
Huawei R4815G1Rectifier Module is a high-efficiency, high-power-density digital rectifier module, which realizes the conversion of 85V AC～300V AC input and 53.5V DC default output. It has the advantages of soft start function, perfect protection function, low noise, and parallel connection. The new power monitoring technology is adopted to realize the real-time monitoring of the status of the rectifier module and the load, and realize the function of adjusting the output voltage through the background. It is designed to be less than IU in height and supports an online hot-swappable design. It is easy to install and operate, and suitable for embedded communication power systems such as Huawei ETP4890-A2, ETP4830-A1. |
Packaging & Delivery
| Packaging: | 1 pc/ctn |
|---|---|
| Delivery/Lead Time: | 6 |
| Production Capacity: | 666 |
Product Description
Huawei R4815g1 48V 15A 870W Rectifier Module
Huawei R4815G1 Rectifier Module Product Features
High efficiency: >96%
Input voltage range: 85~300VAC
Operating temperature range: -40~+75ºC
Total harmonic distortion(THD): ≤5%
Hot-plug
Digital control
Intelligent electric meter
Communication over CAN
Adjustment of voltage and current
Meet RoHS requirements
Passing the TUV, CE, CB, UL certifications
Huawei R4815G1 Rectifier Module Product and More related models
Part Number Input Voltage Output Voltage Output Power Efficiency Operating Temperature
R4805G1 85-300Vac 42-58Vdc 270W 94 % -40C to +75C
R4815G1 85-300Vac 42-58Vdc 870W 96 % -40C to +75C
R4815N1 85-300Vac 42-58Vdc 1000W 94 % -40C to +75C
R4830G1 85-300Vac 42-58Vdc 1600W 96 % -40C to +75C
R4830G2 85-300Vac 42-58Vdc 2000W 96 % -40C to +75C
R4830N2 85-300Vac 42-58Vdc 1605W 94 % -40C to +75C
R4850G1 85-300Vac 42-58Vdc 3000W 96 % -40C to +75C
R4850G2 85-300Vac 42-58Vdc 3000W 96 % -40C to +75C
R4850N1 85-300Vac 42-58Vdc 2900W 92 % -40C to +75C
R4850N2 85-300Vac 42-58Vdc 3000W 94 % -40C to +75C
R48100G1 260-530Vac 42-58Vdc 6000W 96 % -40C to +75C
R33640G1 260-530Vac 300-400Vdc 15kW 97% -40C to +75C
R50030G1 260-456Vac 300-500Vdc 15kW 95.8% -30C to +65C
|
