Hifoune High Quality Diesel Forklift C Series FD20T
| Price: | US$ 7681 / Set |
|---|---|
| Minimum Order: | 1set |
| Payment Terms: | T/T |
| Port of Export: | Xiamen |
Product Details
| Model No.: | FD20T | Brand Name: | Hifoune |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Power Unit Diesel Transimission Box Type Electronic hydraulic transmisson Rated Capacity 2000kg Load Center 500mm |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | |
| Production Capacity: |
Product Description
Model UNIT
FD20T
Specifications
Power Unit
Diesel
Operator Type
Driver/Seat
Transimission Box Type
Electronic hydraulic transmisson
Rated Capacity
kg
2000
Load Center
mm
500
Max.Lifting Height
mm
3000
Tire Type
Pneumatic Tire
Tire Number
Front
2
Rear
2
Tire Size
Front
7.0-12-12PR
Rear
6.0-9-10PR
Performance
Lifting Speed
Loaded
mm/s
500
Unloaded
550
Lowering Speed
Loaded
mm/s
480
Unloaded
450
Travelling Speed
Loaded
km/h
17
Unloaded
19
Max.Gradeability (Loaded)
%
21
Max.Drawbar Pull (Loaded)
kn
18
Mast Tilting Angle (Fwd/Bwd)
deg
6/12
Free Lifting Height
mm
150
Turning Radius
mm
2170
Dimensions
Overall Length (with fork)
mm
2605
Overall Width
mm
1150
Overhead Guard Height
mm
2090
Fork Size (LxWxT)
mm
1220×122×40
Mast Height (Fork lowered)
mm
2090
Battery (Voltage/Capacity)
V/Ah
12/90
Truck Weight
kg
3380
Fuel Tank Capacity
L
70
Engine
Brand
XINCHAI
MITSUBISH
ISUZU
Model
C490
S4S
C240
Rated Power
kw/rpm
40/2650
35.3/2250
35.4/2500
Rated torque
n-m/rpm
160/1600-2000
169/1700
137.7/1800
Number Of Cylinder
4
4
4
Displacement
2.67
2.49
2.37
|
