HVJ3 7.2KV VACUUM CONTACTOR
| Price: | US$ 377 / Piece |
|---|---|
| Minimum Order: | $20000.00 |
| Payment Terms: | T/T |
| Port of Export: | Ningbo or Shanghai |
Product Details
| Model No.: | HVJ3 7.2KV | Brand Name: | JUCRO |
|---|
| Certification: | |
|---|---|
| Specification: |
1. General
The vacuum contactor is mainly used in the power system with AC 50Hz and rated voltage 7.2kV, for making or breaking circuit and to make electromagnetic starter with suitable protective device and F-C switchgear. |
Packaging & Delivery
| Packaging: | plywood boxes |
|---|---|
| Delivery/Lead Time: | 30days |
| Production Capacity: |
Product Description
2. Working condition:
1) Altitude should not be over 1,000m;
2) Ambient temperature: -5~40ªC;
3) Average temperature in 24 hour not exceed 35ªC;
4) When the highest temperature is 40ªC, the relative humidity should not be higher than 50%;
5) Pollution degree: class 3
Main models and technical parameters
Rated voltage: 7.2 kv
Control voltage: 380/220/110
Rated current: 160A, 250A, 400A, 630A, 800A, 1000A
Clearance: 3.5«0.3 mm
Over travel: 2«0.2 mm
Pressure: >85N
Main circuit power frequency withstand voltage: 32000 v
Auxiliary circuit power frequency withstand voltage: 2500 v
Control circuit power frequency withstand voltage: 2000 v
Making capacity: 10Ie,100 times
Breaking capacity: 8Ie,25 times
Limit opening current(A): 10Ie
Overload: 8Ie,10 s
Mechanism life: 1 million times
Weight: 25.5 KG
Note: “Ie” represents the rated current of main circuit
|
