HVJ20 2KV 630A vacuum contactor
| Price: | US$ 324 |
|---|---|
| Minimum Order: | $20000.00 |
| Payment Terms: | T/T |
| Port of Export: | Ningbo or Shanghai |
Product Details
| Model No.: | HVJ20 2KV 630A | Brand Name: | JUCRO |
|---|
| Certification: | |
|---|---|
| Specification: | HVJ20 2KV 630A vacuum contactor has higher rated current, smaller size and anti-dusty advantages. It can be used in AC50 ~ 60Hz, 2KV power system, rated current to 800A, for long distance making-breaking and frequent starting and controlling of AC motor. |
Packaging & Delivery
| Packaging: | cartons and plywood pallet |
|---|---|
| Delivery/Lead Time: | 30days |
| Production Capacity: |
Product Description
HVJ20 series vacuum contactor has higher rated current, smaller size and anti-dusty advantages. It can be used in AC50 ~ 60Hz, 2KV power system, rated current to 800A, for long distance making-breaking and frequent starting and controlling of AC motor.
Rated voltage: 2 kv
Rated current: 630A
Main circuit making ability (A/100 times): 6300
Main circuit break-make ability (A/10 times): 5000
Maximum breaking ability (A/3 times): 6300
Electrical life AC3(times): 600,000
Electrical life AC4(times): 100,000
Mechanical life(times): 1,000,000
Rated operating frequency AC3(times /h): 300
Rated operating frequency AC4(times /h): 120
Short-time operating frequency times /h(20S): 1200
Clearance between open contacts(mm): 3¯0.3
Over travel(mm): ≥1
|
