Green Laser Module,532nm, Dot or Line, 30mW,50mW,100mW

Green Laser Module-Line

Features:
 Crystal-growing experience for 15 years
 Cost effective
 High stability and reliability
Applications:
 Laser Level Gauge
 Marble cutting Positioning
 Machinery Positioning

Specifications:

Items Parameters
Part No. LMGL-10/20
Wavelength (nm) 532+/-1nm
Line Power 10-20mW (+/-2mW )
Input Voltage DC 3.7V
Input Current <250mA
Line Width (5m) <2mm
Divergence Angle 120®
Housing Material Aluminum alloy
Operating Temperature 0~45®C
Storage Temperature -40 ~+70®C
Expected Lifetime >5000hrs
Warranty Period 6 months
Dimension D15*L30mm
Note: 1. Customized Sizes available upon request.




Red Laser Module-635nm
Features:
 Manufacturing experience for 15 years
 Cost effective
 High stability and reliability
Applications:
 Industrial Marker
 Military instruments and equipment
 Experimental Light Source
 Laser aiming

Specifications:

Items Parameters
Part No. LMRD-635-07/15
Wavelength (nm) 635+/-10nm
Line Power >7-15mW
Input Voltage 3.0-5.0V
Input Current <30-60mA
Beam Size (100m) <70mm
Housing Material Copper or Aluminum Alloy
Operating Temperature -20~+65®C
Storage Temperature -40 ~+80®C
Expected Lifetime >5000hrs
Warranty Period 6 months
Dimension D7*L33mm
Note: 1. Customized Sizes available upon request.
