Good oil yield recycling tire into oil plant

The main working process of recycling tire into oil plant: Put waste tires into the reactor, then heat; Under high temperature, waste tires will be pyrolyzed; Oil gas will come out and goes to cooling system cooled into liquid.

The main working process of recycling tire into oil plant

a> Use auto-feeder to feed the waste tires/plastic into pyrolysis reactor automatically, seal the feeding inlet door tightly.

b> Heat the reactor by burning the following fuel material: coal, wood, natural gas, or fuel oil in the combustion system. The reactor will be heated slowly, when the temperature reaches around 250 degree Celsius, the oil gas will be formed.

c> After processed by DOING's recycling tire into oil plant, the oil gas will go to the cooling system to be liquefied. The gas which can not be liquefied under normal pressure will be designed to go back to combustion system through safety device instead of the fuel material to burn the reactor, which is environmental friendly and can save you much energy.

d> After finishing oil collecting, the temperature of reactor will be down, while, carbon black can be discharged automatically at the same time.

e> When the temperature falls down to 100 degree Celsius, workers can open the door of reactor to discharge the steel wire.

f> Start another batch working.
