GBW horizontal centrifugal chemical resistant pump for sulfuric acid
| Price: | US$ USD950 / Unit |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | T/T in advance |
| Port of Export: | SHANGHAI |
Product Details
| Model No.: | GBW65-200 | Brand Name: | kenshine-pump |
|---|
| Certification: | GS,ISO |
|---|---|
| Specification: |
GBW pump Performance sheet:
Model Flow rate Head Speed Motor power (m3/h) (m) (r/min) (Kw) GBW25-125 4 20 2900 1.1 GBW25-160 4 32 2900 2.2 GBW32-125 5 20 2900 1.1 GBW32-160 5 32 2900 2.2 GBW40-125 6.3 20 2900 1.5 GBW40-160 6.3 32 2900 3 GBW40-200 6.3 50 2900 5.5 GBW50-100 12.5 12.5 2900 1.5 GBW50-125 12.5 20 2900 2.2 GBW50-160 12.5 32 2900 4 GBW50-200 12.5 50 2900 7.5 GBW65-100 25 12.5 2900 2.2 GBW65-125 25 20 2900 4 GBW65-160 25 32 2900 5.5 GBW65-200 25 50 2900 11 GBW80-100 50 12.5 2900 4 GBW80-125 50 20 2900 7.5 GBW80-160 50 32 2900 11 GBW80-200 50 50 2900 18.5 GBW100-100 100 12.5 2900 7.5 GBW100-125 100 20 2900 15 GBW100-160 100 32 2900 18.5 GBW100-200 100 50 2900 30 GBW125-100 160 12.5 2900 15 GBW125-125 160 20 2900 18.5 GBW125-160 160 32 2900 30 GBW125-200 160 50 2900 45 GBW150-125 160 20 2900 18.5 GBW150-160 160 32 2900 30 GBW200-200 200 12.5 2900 18.5 GBW200-250 200 20 2900 22 GBW250-250 550 20 2900 55 |
Packaging & Delivery
| Packaging: | plywood case |
|---|---|
| Delivery/Lead Time: | 7 Days |
| Production Capacity: | 1000Units per month |
Product Description
GBW Concentrated Sulfuric acid Pump
Pump Introduction:
GBW of concentrated sulfuric acid pump is the designed and made centrifugal pump according to IS Series pump performance parameters. GBW concentrated sulfuric acid pump is made of cast iron and carbon steel two special materials and with the outstanding hydraulic model as the new chemical pump.
Shaft seal is for outer mounted mechanical seal with high quality. Dynamic and static rings are made of hard alloy or ceramic. The seal has the advantages of wear resistance and
no leakage and long life etc.
GBW special carbon steel centrifugal pump is used to transfer concentrated sulfuric acid with concentration from 80% to 98% and the temperature is from 25 degree Celsius to 60 degree Celsius.
GBW Special cast iron centrifugal pump is used to transfer concentrated sulfuric acid with concentration from 80% to 98% and the temperature is from 25 degree Celsius to 50 degree Celsius.
Model meaning:
GBW 25-125
GB – concentrated sulfuric acid pump
W – Horizontal
25 – Diameter of pump inlet and outlet
125 – diameter of impeller
Performance range
Flow:4~550m3/h;
Head:12.5~50m;
Rotary speed:1450,2900r/min;
power:1.1~55KW
|
