Fully Automatic 5-Wire Multi Cut Strip Twist Tin Crimping Machine

Introducing the Ultimate Wire Processing Powerhouse: The Automatic Crimping Machine
This high-performance Automatic Crimping Machine revolutionizes your wire termination process, integrating cutting, stripping, twisting, and tinning into a single, efficient operation for up to 5 wires simultaneously.

Key Advantages:

Unmatched Multi-Wire Processing: Manage five wires at once, significantly boosting production output and reducing labor costs.
All-in-One Functionality: Cut, strip, twist, and tin wires in a single streamlined operation, minimizing processing time.
Exceptional Precision Control: Advanced servo control and high-quality components (Huichuan servo motors and Yadeke pneumatic cylinders) ensure consistent, reliable results on every wire processed.
Versatile Wire Compatibility: Handles a wide range of wire types and sizes (AWG16-AWG30).
User-Friendly Operation: The intuitive touchscreen interface with an English operating menu facilitates easy operation for workers of all skill levels.
Simplified Maintenance: Fast and efficient process and material changeovers combined with user-friendly maintenance procedures minimize downtime and maximize productivity.
Technical Specifications:

Model Name (for reference): Not provided
Functions: Wire cutting, single-end stripping, double-end stripping, single-end terminal crimping, single-end twist, single-end tin coating (optional)
Cutting Length: 35mm-650mm
Cutting Accuracy: 0.2+/-0.02L
Stripping Length: Front End: 1-6mm, Back End: 1mm-10mm
Wire Diameter: 1mm-3.5mm
Tin Coating Length: 1mm-10mm
Twist Length: 2mm-10mm
Common Wire Diameter: AWG16-AWG30
Crimping Force: 2.0 Ton
Working Efficiency:
Cutting Length 100mm: 5500 pieces/hour
Cutting Length 200mm: 4600 pieces/hour
Air Pressure: 0.5-0.7 MPa
Detection Devices: Terminal crimping detection, missing wire detection
Tool Material: High-speed steel
Dimensions: 180 x 98 x 160 cm (standard machine)
Net Weight: 290 Kg
Auxiliary Device: Terminal waste paper collection device
Power Supply: AC220V Single-Phase 8A (customizable)
The Automatic Crimping Machine is a perfect solution for businesses seeking to revolutionize their wire processing operations. Its exceptional efficiency, multi-functionality, precision control, user-friendly design, and versatility make it a valuable asset for any high-volume production environment.
