Frameless Folding Glass Partition Wall Easy Install Sliding Glass Movable Partition for Balcony

The GreatFold is aluminum-framed operable partition is the most versatile operable wall constructed today. Partitions are a series of flat panels, approximately range from 600mm(23") to 1200mm(47") wide. They have a wide array of features and options to meet most design and budget requirements. Models are acoustically rated, available in 65mm(2.6") ,80mm(3")or 100mm(4") thick models, and in single, pair hinged configurations.
Our Advantage
Our easy lock-up set, Retractable pressure seals on top and bottom are extended and retracted by a single 180®turn removable operating handle.
Retractable Pressure Seals--Once the panel is positioned, they are sealed in place with retractable pressure seals
Telescopic sleeve panel--Final closure of the wall is achieved by extending a telescopic sleeve on the last panel. The sweep strip simultaneously extends the top and bottom. The rubber sealing strip on the side edge of telescopic panel can seal the wall tightly to reach acoustic integrity.
Product Information
• Panel Suspension: Top hunge system without the need for a floor track.
• Panel Width: Each panel 600mm-1200mm.
• Track: Aluminum OR Steel Track
• Roller on panel: Single or double roller.
• Panel Frames: Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
• Top&bottm seals: Top and bottom pressure retractable seals ensure effortless moved and locked.
• Panel stacking: Numerous panel stacking options for complete flexibility.
• Panel face: MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.

Movable Partition Walls System-Technical Information
TYPE 65A 80A 100A&125A
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm 100mm
Panel height Up to 4000mm,Heights greater than 3000mm refer to our Technical Dept Up to 6000mm,Heights greater than 6000mm refer to our Technical Dept.inset Pass doors above 2400mm.Full Height pass door up to 3000mm high Document 'M'disabled doors-optional
Max height 4000mm with heavy duty track 6000mm with heavy duty track 18000mm with heavy duty track or steel track
Panel width 600-1200mm 600-1200mm 600-1200mm
Frame construction Aluminium/steel Aluminium/steel Aluminium/steel
Face material 12mm 12/15/18mm 12/15/18mm
Fire safety optional Class I or O optional Class I or O optional Class I or O
Vertical profiles Aluminium,anodised with sealing profiles,painted-optional Aluminium,anodised with sealing profiles,painted-optional Aluminium,anodised with sealing profiles,painted-optional
Retractable seals Aluminium,black with double rubber seals Aluminium,black with double rubber seals Aluminium,black with double rubber seals
Operation of seals Manual,with supplied operating handle Manual,with supplied operating handle Manual,with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass Doors Single open in oanel or double open in two panel Single open in oanel or double open in two panel Single open in oanel or double open in two panel
Sound insulation 40,44,47,50dB Rw 40,44,47,50,53dB Rw 40,44,47,50,53,58dB Rw
Weight Approx 33-40kg/sq M Approx 43-50kg/sq M Approx 63-70kg/sq M
FAQ
How to select the suitable movable wall for your site?
We have 4 types of movable wall,65type,80type,100type and 125 ultra-high type. You can choose the right movable wall upon the Height and Soundproof requirement as following,
65type-- Max height 3.5m, soundproof: 38dB to 43dB
80type- Max height:5.5m,Soundproof: 43dB to 53dB
100type--- Max height:7m,Soundproof: 43dB to 58dB
125ultra-height---Max height:17m,Soundproof: 38dB to 48dB

What you should do on site?
A beam(truss) should built on site for track installation.The min distance leaving for track installation from false ceiling to top ceiling is 200mm.

How to install?
We will provide the installation manual and video guiding the installation job. We can also dispatch the installation engineer supervising the installation as request.

What is lead time?
The lead time is 7 days to 10 days.

How to transport?
Sea transport is a common mode of transportation. In an emergency, can be air freight.

How do the goods packing?
corrugating paper packaging, MDF batten cover all around corner.
The movable wall panel and track, fittings will be packed separately.

What is Procurement procedure?
Firstly, send us the shop drawings(if the shop drawings is not available, you can tell us the height from false ceiling to finished floor and width from wall to wall)
Secondly, we offer you the movable wall layout drawings for your confirmation
Thirdly, we quote the movable wall in accordance with confirmed drawings.

What is finishing face?
The bottom panel is MDF or plywood, which is unfinished face. You can do decoration on site, such as wallpaper, paint, etc.
We can also provide the product with finished face, such as faux wood, Woven fabric and Leather.
