Forged Gate Valves, Npt End,Body:,ASTM A-105, Stem F6, Trim: 13% CR
| Price: | US$ 100 |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | shanghai |
Product Details
| Model No.: | Z41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | China Forged Gate Valves Manufacture,Stv Provide Forged Gate Valves, Npt End,Body:,ASTM A-105, Stem F6, Trim: 13% CR |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Product Detail
Design Standard: API602.
Body Material: A105
Nominal Diameter: 2 Inch (DN50).
Pressure: Class 800.
End Connection: NPT.
Face to Face: ASME B16.10.
Working Temperature: -29℃~+425℃.
Mode of Operation: Handwheel.
Test and Inspection: API 598.
Product Range
Body Material: A105、LF2、F5、F11、F22、304、304L、316、316L、F51、F91、20#、Inconel .Ect
Normal diameter: 1/2"~3" (DN15~DN80).
End connection: NPT, SW, Butt-Weld, Flanged.
Pressure range: 150lbs~2500lbs(PN10~PN420).
Operation: Hand wheel, Electric,Pneumatic Actuator
Working temperature: -196℃~ +560℃.
Product Keywords of Forged Gate Valves, Npt End,Body:,ASTM A-105, Stem F6, Trim: 13% CR
|
