Factory glass wall partition aluminium profile india for restaurant
| Price: | US$ 68 / Square Meter |
|---|---|
| Minimum Order: | 10 |
| Payment Terms: | LC, T/T, D/P, WU, MG etc. |
| Port of Export: | Guangzhou |
Product Details
| Model No.: | GLS-65 | Brand Name: | GreatFold |
|---|
| Certification: | |
|---|---|
| Specification: |
Place of Origin:
Guangdong, China (Mainland) Brand Name: GreatFold Model Number: GLS-G40 Movable Wall Thickness: 10-12 mm, customize available. Width: 600-1100mm Heigth: 2500-3600mm Contract Range: 45mm Sound insulation coefficient: 15-20 db Surface Material: Glass Frame Material: 6063-T6 Aluminum Alloy Weight: 50m or as requested Advantage: Free of floor track Pass door selection: Single or double door |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | |
| Production Capacity: |
Product Description
How to select the suitable movable wall for your site?
We have 5 types of movable wall , 65type , 80type , 100type and 125 ultra-high type . You can choose the right
movable wall upon the Height and Soundproof requirement as following,
65 type— Max height 3.5m, soundproof: 38dB to 43dB
80 type— Max height:5.5m,Soundproof: 43dB to 53dB
85 type— Max height:5.5m,Soundproof: 43dB to 53dB
100 type— Max height:7m,Soundproof: 43dB to 58dB
125ultra-height — Max height:17m,Soundproof : 38dB to 48dB
What you should do on site ?
A beam(truss) should built on site for track installation . The min distance leaving for track installation from false
ceiling to top ceiling is 200mm .
How to install ?
We will provide the installation manual and video guiding the installation job . We can also dispatch the installation
engineer supervising the installation as request .
What is lead time ?
The lead time is 7 days to 10 days .
How to transport ?
Sea transport is a common mode of transportation. In an emergency, can be air freight.
How do the goods packing ?
Corrugating paper packaging, MDF batten cover all around corner .
The movable wall panel and track, fittings will be packed separately .
What is Procurement procedure ?
Firstly , send us the shop drawings(if the shop drawings is not available , you can tell us the height from false ceiling
to finished floor and width from wall to wall)
Secondly , we offer you the movable wall layout drawings for your confirmation
Thirdly , we quote the movable wall in accordance with confirmed drawings .
GreatFold partition movable freely, easy installation, good acoustic effect, nice surface treatment, anti corrosion.
Technical Description Feature
1. Change the room space flexibly.
2. Heavy Track loading capacity make sure the safety of Partition.
3. Precise welding between separate rail can avoid repairing and maintenances in high probability.
4. Partition retract and push easily, only one person can handle the moving job.
5. Wide application: can be used in Office place, commercial place, exhibition place, Hospital place, etc.
100% Manufacturer - 100% Customized Offer -
Free Floor Planning CAD Offer - Contact Now!
|
