Factory Price EN 124 F5 Cast Iron Hatch Gate Valve

Product Name
Ductile Iron DIN3352 F5 Gate Valve DN80
Materials
Ductile iron,Casting
Nominal diameter:
DN40-400 / 1.5inch-24inch
Temperature range:
0℃-80℃
Working Pressure
PN10/16
Suitable medium:
fresh water,waste water,sewage,air,food,oil etc.
Face to Face:
DIN3352-F4/F5
Connection Ends
Flange to BS EN 1092-2:1997
Stem
Stainless Steel,Carbon steel
Color
Clients' requirement
1. Soft sealing gate valve main features are as follows:

1. Integral gluing: the gate adopts the whole package, its good coverage and accurate geometry, ensure the sealing is reliable and the service life is long.


2. Light weight: the valve body is made of iron, light weight and convenient installation.


3. Flat seat: the bottom adopts the same flat seat design with the water pipe, not creating debris and silting, and the sealing is more reliable.

4. Corrosion resistance: the inner cavity is coated with non-toxic epoxy resin to prevent corrosion and rust, not only for drinking, but also for sewage system.

5. 3 "0" seal: the stem is sealed with three 0-type rings, the friction resistance is small, the switch is light and not leaking.

The company can configure various electric, pneumatic and other driving devices according to customer's specific requirements.
