FNC20 Hydraulic Hose Crimping Machine

FNC20 Hydraulic Hose Crimping Machine
Feature description：
● Precision Digital Control
● Main Parts made in Germany
● Designed for Mass Production
● Energy Saving and Safety Operation
● Europe CE Approved
Specification：
Main Specification
FNC20
Max Hose Size
11/4”
Crimping Range ( mm )
4-65
Die Type
P32
Max. Opening ( mm )
22
Master Die ( Die / Length )
+20
Motor KW
4 by SIEMENS
Voltage ( v )
220V / 440V
Crimping Force ( kN )
500
Crimping Hour
2500
Noise level ( dB(A) )
71
Protection Class
IP54
L*W*H (mm)
685*1000*940
Weight ( kg )
340
Standard Die Sets Included:
Die NO.
12
14
16
19
22
26
30
34
39
45
52
57
Crimping Range
12-14
14-16
16-19
19-22
22-26
26-30
30-34
34-39
39-45
45-52
52-57
57-66
Length
3
3
4
4
4.5
4.5
5
5
5
5
5
5
*In addition to the standard die sets, a wide range of special die sets for different diameters,
lengths and forms is available
Order No.
220V, 400V, 415V, 440V,480V 3 phase :00005810
220V 50/60hz single phase :00005812
