European Type Jaw Crusher

European Type Jaw Crusher
Type: Primary Crusher
Input Size: 180-930mm
Processed Materials:
Iron ore, copper ore, gold ore, manganese ore, river stone, gravel, granite, basalt, minerals, quartz, diabase, etc..
Applications:
Mining, metallurgy, construction, highway, railroad, and water conservancy, etc.
Features：
1.World-level manufacturing technology is adopted, and highest-level raw material is used.
2. Central lubricating device are installed on the machine, so the bearing is easy to be lubricated.
3. Adjustment of the discharge part is more convenient. The adjustment methods: gasket adjustment, hydraulic assistant adjustment, wedge block and wedge hydraulic adjustment.
4. More advanced movable jaw assembly lengthens life of crusher. Movable jaw assembly is made from cast piece with high-quality, is driven by two large flying wheels which are made from cast steel. Moreover, heavy eccentric shaft is processed by forged mold. All of these make the European Type Jaw Crusher extremely reliable.
5. Integral cast steel structure is adopted for bearing seat. Integral cast steel bearing matches well with the crusher frame, at the same time, radial strength of the bearing seat is highly strengthened. However, the separate bearing seat does not have this advantage.
6. Finite element analysis technology is adopted to make the crusher much stronger.
7. Crusher chamber adopts "V" structure which could make actual feed width comply with the nominal one.
8. Bearing with larger model and higher load are used. All jaw crusher is equipped with larger bearing compared with same model of normal jaw crusher. Its higher load capacity and effective oil seal will lengthen the life of bearing.
9. A newly designed tooth-shape side plate, makes the available area of jaw plate longer, and enhances the capacity.
10. Pressing bar and support type are used to fix jaw plate.
11. Heavy type protecting plate is installed for bearing seat, accidental damage of bearing seat is avoided.
12. Supporting bar under jaw plate protects movable jaw and frame from being worn down.
CASE：100TPH feldspar crushing line in Jambi, Indonesia
One of our Indonesia customers bought a 100TPH stone crushing line for feldspar processing. LIMING designed the whole line, and it runs stable with few breakdowns. The finished products are well distributed, meeting customer’s needs of making ceramics and floor tile.
Equipment: Vibrating feeder GZD 960X3800, jaw crusher PE600X900, 4 sets secondary jaw crusher PEW250X1200, 2 sets cone crushers HPT220(F), Vibrating feeder GZD100-4(L), 3 sets vibrating screen 2YZS1860, 2 sets cone crusher HPT300(F), roller crusher 2PG0608
Using Time: sinceMarch2015
Processed Material: feldspar
Final products size:0-5mm
Capacity: 100tph
Place of use: Jambi, Indonesia
Applications: Used for ceramics and floor tile
Liming has the right crushing, grinding and beneficiation solution for your choice. Contact us now for more information.
