Epoxy Film thermistor
| Price: | US$ 0.05 |
|---|---|
| Minimum Order: | 1000 |
| Payment Terms: | T/T, L/C, D/A, D/P ,West side,Paypal Money, Gram |
| Port of Export: | Shen zhen |
Product Details
| Model No.: | ntc,ptc | Brand Name: | yaxun |
|---|
| Certification: | SGS |
|---|---|
| Specification: |
Second: Features:
1: MF5B series of products for the co-directional thin-film package type 2: insulation film packaging, thermal induction speed, high sensitivity 3: good stability and high reliability 4: good insulation 5: high precision resistance 6: small size, light weight, rugged, easy to install automatically Three: product model description MF 5B 103 F 3950 ① ② ③ ④ ⑤ ①MF ¤ - negative temperature coefficient (NTC) thermistor code. ② 5B - thin film thermistor. ③103 - thermistor nominal resistance, said the resistance of the nominal resistance: 10 × 103 (Ω). F = © 1%, G = © 2%, H = © 3%, J = © 5% of the resistance value (accuracy) ⑤ 3950 - resistance of the thermal index (material coefficient) B value: 395 × 10 (K) F = © 1%, G = © 2%, H = © 3%, J = © 5% of the resistance value (accuracy) ⑤ 3950 - resistance of the thermal index (material coefficient) B value: 395 × 10 (K) MF5B series of products using Note: 1: Do not arbitrarily bend resistance wire frame, So as to avoid chip and cable off, Causing poor resistance 2: welding temperature should not exceed 300 ℃, Welding time is best not more than 0.5 seconds 3: thermal casing using hot air gun, Air gun temperature should be controlled at about 120 ℃ 4: When welding using a constant temperature soldering iron, Tip flat, One hand to get resistance, One hand to wire touch welding, Can improve production efficiency and shorten the welding time 5: Special Note: Do not touch the chip hand (that is, resistive top) |
Packaging & Delivery
| Packaging: | Carton |
|---|---|
| Delivery/Lead Time: | 7 DAY |
| Production Capacity: | 1000000 |
Product Description
Five: MF5B series model specifications
Model Rated resistance value B value Operating temperature
R25 (KΩ) Precision (25/50℃) (25/85℃) Precision (℃)
(K)
MF55□502□3270A 5 ©1％
©2％
©3％
©5％ 3270
©1％
©2％ -50～260
MF55□502□3470A 5 3470
MF55□103□3380A 10 3380
MF55□103□3435B 10
3435
MF55□103□3470B 10
3470
MF55□103□3950A 10 3950
MF55□103□3975B 10
3975
MF55□203□3950A 20 3950
MF55□303□3950A 30 3950
MF55□473□3950A 47 3950
MF55□503□3950A 50 3950
MF55□104□3950A 100 3950
|
