China suppliers sea water ice machine 1ton
| Price: | US$ 10000 |
|---|---|
| Minimum Order: | 1 SETS |
| Payment Terms: | T/T |
| Port of Export: | SHENZHEN |
Product Details
| Model No.: | KMH | Brand Name: | ICEUPS |
|---|
| Certification: | CE,ISO9001 |
|---|---|
| Specification: |
DAILY CAPACITY(24H):20000kg
REF.CAPACITY(KW):130/h EVAPORATING TEMP.:-22℃ CONDENSING TEMP.:40℃ COMPRESSOR TYPE:Semi-hermetic screw COMPRESSOR BRAND:Hanbell / Bitzer TOTAL POWER(KW):75.8 COMPRESSOR IN-POWER(KW) :71.3 REDUCER IN-POWER(KW):1.5 CIRULATING WATER PUMP POWER(KW):0.85 COOLING FAN MOTOR POWER(KW):1.05 POWER SUPPLY:3P-380V-50Hz WATER PRESSURE:0.1Mpa-0.5Mpa REFRIGERANT: R404a ICE TEMP.:-6℃ FLAKE ICE THICKNESS:1.5mm-2.2mm AMBIENT TEMP.:25℃ WATER TEMP. :18℃ SUPPLY WATER WAY:freshwater COOLING WAY:Water cooling RUNNING NOISE(dB) :55dB ICE DENSITY:400~400kg/m3 ICE MACHINE DIMENSION(LxWxH):3695mmX2090mmX2050mm ICE STORAGE DIMENSION(LxWxH):3500mmX3000mmX2500mm ICE STORAGE CAPACITY :12500KG GROSS WEIGHT:4000KG |
Packaging & Delivery
| Packaging: | standard package |
|---|---|
| Delivery/Lead Time: | 15-30 WORKING DAYS |
| Production Capacity: | 50 SET PER MONTH |
Product Description
1.ICEUPS Ice Evaporator use the intelligent design, it is stable,efficient energy and maintain easily.
2.Ice Evaporators are made by SUS304 stainless steel or Chromed-carbon steel,internal spiral groove design,V groove welding technology, it saves 5%~8% energy more than the same type of energy-saving equipment industry
3.Ice Evaporators are processed by high temperature annealing,eliminate the internal stress of steel,the equipment doesn’t distorted to work for long term under low temperature and low pressure.
4.the inner of evaporators is paint handling,so that the flow channel welds permanent styling and never produce Refrigerant leak.
5.Parts of refrigeration unit are from the world famous brand,more stable quality and superior performance, the buyers can find parts in the local markets,so to save significantly the maintenance costs.
|
