A brief introduction of fluorine skateboard rubber bearings
Tetrafluoroethylene skateboarding rubber bearing is on the surface of ordinary plate rubber support stick after a 1.5 mm - 3 mm thick layer of teflon plate, can be made into rubber bearing, and call it: four fluorine slide type bearing (GJZF4, GYZF4 series).Besides GYZ series rubber bearing all the features, ptfe plate (F4) and low coefficient of friction between beam bottom of stainless steel plate, the horizontal displacement of the structure of the upper shear deformation of the bearing itself without limit, can meet the requirements of some large displacement of the bridge.In addition to the function of spherical crown rubber bearings, this plate is especially suitable for bridge of large displacement.Widely used in this factory, mining, machinery, electronics, mechanical equipment, kitchen equipment.
The use range of the rubber support for the tetrafluorotype
A. Use of movable support: mainly used in the long span bridge of the long span of > 30 meters and the continuous girder bridge.
B. As a sliding block, use continuous beam jacking, T beam traverse, large equipment slip.
Iii. F4 rubber bearing schematic diagram
The load level is divided into 100KN-10000KN
The minimum thickness of polytetrafluoroethylene sheet that is pasted on a four-fluoro skateboard holder shall be in accordance with the provisions of table 4.Units: mm
Rectangular support round bearing
Long edge range thickness (d) thickness
500 500 or less 2 or less
3 > 500 > 500
4. The specification of rubber bearing of teflon
1. According to the department of transportation's JT/T 663-2006 road bridge sheet rubber support specification series, please click enter.2. The special specifications may be negotiated and produced by the user.4. Beam bottom steel plate and stainless steel plate can be supplied.
