CT-6090-UAV Anti-Drone UAVs Portable Jammer 700W 8 bands up to 6km

CT-6090-UAV Anti-Drone UAVs Portable Jammer 700W 8 bands up to 6km


Extreme powerful Anti-Drone UAVs portable Jammer
Cover 100% Drones UAVs, 360 Degree Omni Antrnna
8 Bands, 700W, Pelican Case 1620 + Tripod + Antenna Frame
2.4Ghz 5.8Ghz Vertical+Horizontal Polarization 4 bands in big Omni Antenna

CT-6090-UAV 8 Band specification :
4 band in One Big Omni Antenna Φ76*620mm
1. 5.7-5.9GHz 50W RC 5.8Ghz (Vertical Polarization)
2. 5.7-5.9GHz 50W RC 5.8Ghz (Horizontal Polarization)
3. 2.4-2.5GHz 100W WiFi 11.g, b, Bluetooth ( Vertical Polarization)
4. 2.4-2.5GHz 100W WiFi 11.g, b, Bluetooth ( Horizontal Polarization)
5. 1560-1620MHz 100W GPS L1+Glonass L1+GALILEO E1 + BeiDou B1 Freq
6. 433MHz: 100W Remote Control Omni Antenna
7. 860-920MHz: 100W Remote Control : Omni Antenna
8. 1160-1280MHz 100W GPS L2 + Glonass L2 + BeiDou B3 Freq + GALILEO:E6
GPS L5 + BeiDou B2 + GALILEO: E5 + E5A, + E5B
Total : 700W

Jamming Range Radius 2000~6000 Meters ( Omni Antenna 360 degree )
Cover All 100% Commercial Drones / UAVs. Like DJI Phantom 4 Pro V2.0, Phantom 4, Phantom 3 Professional, Advanced, Standard series, Inspire Series...
Adjustable Output Power each Band/Channel, Max Output Power to 0 (OFF)
100% Safe VSWR over protection (Isolator) for each modular
Included Tripod with Antenna’s frame easy to install on field
Power supply: AC110 or 220-240V/DC 27V
(External Battery 40-60min B-50AH Option)
Working time:Without the time limit, May continue to works
Dimension: 626 mm(L)×49.2mm(W)× 350mm(H) Pelican Case 1620
Weight : 45kg

Package contents:
1 pc main jammer
2 pcs Omni antennas 750mm long
3 pcs Big Omni Antennas
1 pcs AC Adapter (AC 220V-DC 27V or 24V/45 Amp)
1 pc Wireless RC that works on AC Adapter
1 pc Portable Tripod + Antenna Frame







2 Years warranty, Neutral packing, OEM Manufacturer :
