COLOR COATED ALUMINUM COIL&SHEET

Name Color Coated Aluminum Coil&Sheet
Standard AISI, ASTM, BS, DIN, GB, JIS
Material 1050,1060,1070,1100, 1200, 1235, 1145, 3003, 3105, 3004, 3021, 5005, 5052, 5083, 5182, 5754, 8011
Brand SHANDONG JINGYU Steel
Thickness 0.2-1.2mm
Width 1600-1250mm
Length According to customer requirements
Temper O-H112, 0 H12 H14 H16 H18 H22 H23 H24 H26
Tolerance +/-0.01mm
Painting Top painting 20-25um and back painting 10 um
Coil ID 75, 150, 200, 300, 400, 505
Color paint PE, SMP, HDP, PVDF
Surface coating, color coating type 1) Material: Pre-treatment material according to your required grade
2) Process: pre-treatment, continuous painting and baking for times

3) Paint: more than 70% of PVDF coating from PPG Corp., the USA and polyester from Sweden Becker Industrial Coating Co., Ltd.

4) Pretreatment: the raw aluminum has to be washed by acid, and chromate. After it is dried out, it will be covered by oxide film to heighten the adhesion.

5) Colors: Can do as your requirement based on RAL color no.

6) Polyester coating single coating, one layer, 18μm; double coating, two layers, 25~27μm. PVDF coating: two layers of PVDF coating, at least 25μm, and if required, it will be covered by another layer of varnish, 35μm in total.



Coil Weight 3-6 ton or as request
Package Standard seaworthy exporting carton, Wooden pallets, waterproof paper and plastic coverage or as per customer’s requirements.
Certification ISO 9001-2008,SGS,CE,BV
MOQ 2 tons
Delivery 10-25days
Monthly Output 3000tons
Application · 1) Construction material further processing
· 2) Solar cell frame, solar battery frame

· 3) Glass curtain wall frame

· 4) Interior decoration

· 5) Elevator decoration

· 6) Signs, nameplate, bags making.

· 7) Automobile parts material

· 8) Office and Household appliances: HVAC equipments

· 9) The consumer electronics: mobile phones, digital cameras, MP3 .etc.

Payment T/T, LC, Kun Lun Bank, Western Union, PayPal etc
Remarks Insurance is all risks and accept the third party test
