Belfone Certified Dmr Two-Way Radio with CE/FCC/IP67 (BF-TD511)
| Price: | US$ 178 |
|---|---|
| Minimum Order: | 5 |
| Payment Terms: | T/T |
| Port of Export: | Shenzhen/Xiamen |
Product Details
| Model No.: | BF-TD511 | Brand Name: | BelFone |
|---|
| Certification: | |
|---|---|
| Specification: |
General:
Version: Basic Frequency Range: VHF: 136-174MHz; UHF: 350-390MHz/ 400-480MHz/ 450-520MHz Channels: 512 Zones: 32 Channel Spacing: 12.5KHz/ 25KHz Working Voltage: DC7.4V (¯20％) Frequency Stability: ¯1.5ppm Antenna Impedance: 50Ω Battery Capacity: Real 2000mAh Battery Average Working Time: Digital 22 hours; Analog 16 hours Dimension: 60.8(L)* 35.7(W)* 118.5(H) mm Weight: 239g (including battery) Transmitter: Power Output: High power: 4.5W; Low power: 1W 4FSK Modulation: 12.5KHz data only: 7K60FX; 12.5KHz data and voice: 7K60FXE FM Modulation: 12.5KHz: 8K50F3E; 25KHz: 16KφF3E Modulation Limitation: +/- 2.5KHz FM Noise: -40dB Spurious Emission: -36 dBm≤1GHz/-30 dBm≥1GHz Adjacent Channel Power: ≤-60dB Frequency Response: +1/-3dB Vocoder: AMBE++ Audio Distortion: ≤3% Receiver: Digital Sensitivity: 5% BER: 0.25 uV Analog Sensitivity: 0.25 uV (12 dB SINAD) Intermodulation: 60dB Adjacent Channel Selectivity: 60dB Spurious Suppression: 60dB FM Noise: -40dB Frequency Response: +1/-3 dB Audio Power: 1.5W Audio Distortion: 3% (typical) Conduction Radiation: -57dBm GPS Precision: Horizontal Accuracy ≤10m (with good signal) TTFF (first location) Cold Boot: ＜1 minute(with good signal) TTFF (first location) Hot Boot: ＜10 seconds (with good signal) Environmental Specifications: Operating Temperature: -20℃~+60℃ Storage Temperature: -30℃~+85℃ Water and Dust Proof: IP67 Shock & Vibration: MIL-STD-810C/D/E/F |
Packaging & Delivery
| Packaging: | Standard Carton Packaging |
|---|---|
| Delivery/Lead Time: | 15 Days |
| Production Capacity: | 100000 Pieces/Month |
Product Description
DMO Pseudo Trunk
The user can choose slot 1 or slot 2 for communications. When one slot is occupied the radio will automatically switch into the free slot. Frequency efficiency is greatly increased.
DMO True 2-Slot
In direct mode, this radio supports two voice calls simultaneously due to DMR two timeslots, which means two communication paths on 1 frequency at no extra costs or frequency license.
Digital/analog Dual Modes
BF-TD511 gives you a smooth transition from analog to digital.
Private Call, Group Call and All Call
The versatile calling functions bring more efficiency to your teamwork.
Long Battery Standard Time
BF-TD511 is a powerful radio with long battery life. (digital 22h& analog 16h)
Excellent Audio Quality
The AMBE3000 vocoder and FEC technology give BF-TD511 loud and clear digital audio.
Transmit Interrupt
This function enables a supervisor to interrupt a radio conversation in order to clear a channel for more important communications.
Remote Kill/Revive
Such functions enable you to kill or revive a radio over the air. This greatly facilitates dispatching work and can be especially useful should a radio happen to be lost. You can easily remote kill the lost radio and confidential information can be kept from leaking out.
Radio Priority-based Interruption
This function enables a radio with a higher level to interrupt communications between radios with lower levels, giving higher priority to radios with higher levels. This means better dispatching efficiency.
Automatic Roaming (Programmable)
In an IP multi-site network, this feature enables BF-TD511 to automatically roam among all sites and stay connected, delivering more flexibility and efficiency.
|
