Battery Testing Equipment;Storage Battery Internal Impedance Tester;Storage Battery Resistance Meter
| Price: | US$ 10500 |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | T/T |
| Port of Export: | Ningbo |
Product Details
| Model No.: | FLD-N1101 | Brand Name: | Falad |
|---|
| Certification: | ISO9001:2008 |
|---|---|
| Specification: |
Characteristic
Applying for the most advanced DC testing method, it real simulates storage battery usage, automatically filters out charger ripple, electromagnetic interference and battery capacitance influence. It can test the storage battery under strong noise environment. The testing data is true and accurate, and can be used online and offline; With “floating current filtering circuit”, no influence from floating current; The test clip adopts the proprietary technology, truly realizes the “four line system” measurement. The measured results are accurate, and with good repeatability and high consistency. It synchronously completes floating charge voltage, battery internal resistance and connection resistance three parameters measurement for one-time; It can automatically judge whether the wiring connection is correct or not, and give the hints. It has anti connection, wrong connection and overvoltage protection function; It has self-diagnosis and self-calibration functions to automatically eliminate zero point deviation and ensure the accuracy of measurement; With built-in memory. It can save 300 sections per group* 10 groups measured data, not lost when power is off; Wide measurement range. It is compatible with 2V, 4V, 6V, 12V, 16V and other specifications batteries; Built-in high capacity rechargeable lithium battery can work for more than 12 hours; The built-in clock can automatically record measurement time and facilitate data tracking; It's convenient to export and upload data with USB communication port; With background management and analysis software. It can analyze and process data, compare with historical data, generate data forms, histogram and other forms of reports, and export data into Excel format files, which facilitate data processing and reporting; LCD liquid crystal display in English, the operation is direct and convenient; The equipment is small, light, easy to carry. It’s equipped with a special backpack and can be operated by one person. |
Packaging & Delivery
| Packaging: | Alloy Case and Wooden Case |
|---|---|
| Delivery/Lead Time: | 5-7days |
| Production Capacity: | 5000/year |
Product Description
Outline
With the increasing dependency of back up systems on battery strings, and the escalating cost of replacing batteries, instrumentation and software systems that can measure, trend and manage the life-cycle of battery cells.It is a cost effective option to choose impedance testing firstly.Impedance testing is an on line test and can be performed frequently to identify individual weak cells before they fail. The battery impedance test helps to identify weak cells before they cause problems, however taking the battery off-line for testing is time-consuming and risky.
Our company developed the “FLD-N1101battery internal impedance tester”, using DC testing method. It automatically selects the test current according to the measured battery capacity, with constant-current discharge in testing process and sets up the “floating current filtering circuit”. It will maximally ensure the authenticity and accuracy of the measurement, and the measured results can be horizontally compared and longitudinally compare with historical data.
|
