BXZ-2L Vertical Backpack Drilling Rig
| Price: | US$ $ 6000 per set / Set |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | tt, lc |
| Port of Export: | qingdao |
Product Details
| Model No.: | BXZ-2L | Brand Name: | Master Machinery |
|---|
| Certification: | iso-9001 |
|---|---|
| Specification: |
BXZ-2L drilling rig Engine brand Kohler House power 7.75 HP Fuel tank capacity 1400 ML Transmission mode gear-driven Starting mode recoil pull starter Clutch mode automatic clutch Coring mode rotary Rate of penetration 540r /min Gear ratio 7:1 Transmission mode CVT (continuously variable transmission) Drill pipe diameter 32mm Drill pipe total length 30m Drill hole diameter 32-120mm Net weight 52 kg Size 550*450*420mm Packing measurement 1050*600*550mm |
Packaging & Delivery
| Packaging: | wooden box |
|---|---|
| Delivery/Lead Time: | 3 days |
| Production Capacity: | 100 sets per month |
Product Description
1.Brief introduction of BXZ-2L backpack drilling rig BXZ-2L vertical knapsack core drilling rig is a removable core sample drilling rig. The rig is mainly used in mineral exploration, geochemical exploration, shallow sampling, geoscience research, geotechnical engineering, engineering investigation, oil field exploration, water conservancy engineering survey, highway engineering survey and so on.
The main features of BXZ-2L vertical backpack core drilling machine are compact structure, detachable, small volume, light weight, easy to carry; imported kohler brand gasoline engine with large horsepower and guaranteed drilling depth with drilling frame. Field operation is more convenient and safe.
Item Parameter Unit Number
Drill rig including stand BXZ-2L Set 1
Drilling pipe including joint 32 *800 mm pc 38
Reducing nipple 46 mm pc 1
Coring barrel 46 *700 mm pc 1
Alloy bit 46 pc 1
Diamond bit 46 pc 1
Reducing nipple 60 pc 1
Coring barrel 60*700 mm pc 1
Alloy bit 60 pc 1
Diamond bit 60 pc 1
Mud pump (gasoline engine) set 1
Inlet hose pipe 20*1000 mm pc 1
Inflow water filter pc 1
Outlet hose pipe 13*1000 mm pc 1
Water supply pipe 13*4500 mm pc 1
Safety clamp grasp 1
Pipe wrench grasp 2
Safety plate pc 1
Spark plug pc 1
Ring gasket Set 1
Water seal Set 1
