Automatic weighing down filling machine manufacturer

Automatic weighing and down filling machine
SCR-1P is a smaller mode of automatic weighing down filling machine, which have been widely used in down jacket production.
If you want to improve filling efficiency, get higher filling quality . Our machine can help you and even more
As following is our product's basic data:
Model No.:SCR-1P
Voltage:220V 50Hz
Dimensions :2.5m×1.6m×1.9m
Power Filling Machine:1.5 kW
Scale:2
Air compressor:l3.5 kW
Filling Material:Down 60 Up
Min Operating Air Pressure:0.58 MPa
Filling Speed:4-8 g/s(adjustable)
Weighing Ability:0.1-30g
Filling Port:1 Pcs
Filling Accuracy:­ 0.03g
Efficiency:2~4 times than manual
Down Storage Volume:5KGS
N.W/G.W:400kg/600kg
Min Operating Space Size:4*3 m
Our advantages:
1.The display accuracy is 0.1g that means save more materials;
2.The power is 1.5kw and compared with old machine it will save more electric;
3.Feather is Circulated in a closed environment, it improves the environment of work place;
4.The operation is simple and one filling machine’s efficiency is equaled 3-4 skilled workers;
5.Good stability ,the key components of filling machine are imported ;
6.Using air pressure to fill, which prevent down to be damaged in filling process
7.OEC service can satisfy customers more

Our details:
patent design makes filling freely for both breathable fabric and non-breathable fabric. And also prevent down going out from the stitches.
Advanced suction device can adsorb feather to improve the environment of work place .
220 valternating current was approved by CA, it  ensures safety.
Down filling machine have automatic warning system. It will reminds operator if the machine does not work properly.
Two scales are out of feather in turns and it improves the efficiency of making down clothing.
Working Principle:High-pressure air is used to absorb the down through the automatic weighing device and to fill the panel with a preset weight of down.
Scope Of Application:down 70/30 up
Buyer Feedback:We Receive One Hundred Percent Of Good Feekbacks From Our Clients
Our Services
After-sale Service:
Main parts apply SIEMENS, SCHNEIDER, DELTA, could live long. And the quality is rlaible and stable.
High quality, low maintanance rate
Make each part standard, could change for you easily
Technicians help setting up and training workers till they could operate well
Warranty:One year, easy-wear parts are excluded.
Package:MDF Board Packing
