Automatic Wire Cut Strip Tin Dip Soldering Machine

Unleash Unmatched Efficiency in Multi-Wire Processing: The DG-01BS Automatic Wire Cut Strip Tin Dip Soldering Machine
The DG-01BS Automatic Wire Cut Strip Tin Dip Soldering Machine represents a revolutionary leap in wire processing technology. This feature-rich machine tackles eight wires simultaneously, performing cutting, stripping, twisting, tinning, and more, all in a single, automated operation.

Key Advantages:

Unparalleled Multi-Wire Processing: Effortlessly manage eight wires at once, significantly boosting production efficiency.
All-in-One Functionality: Integrates cutting, stripping (single or double-ended, with partial stripping options), twisting, tinning, and automatic features like wire feeding, tin wire delivery, and waste collection for a streamlined workflow.
Superior Speed and Efficiency: Achieve impressive production rates of 7000-13000 pieces per hour, depending on wire specifications.
Exceptional Precision Control: Delivers unmatched accuracy in all processing stages with features like computer-controlled knife adjustments and precise length control.
Enhanced User Experience: The intuitive 7-inch KINCO touchscreen interface with Chinese and English language options facilitates easy operation and minimizes training time.
Healthy Work Environment: The automatic smoke absorption system reduces harmful flux fume exposure for operators.
Technical Specifications:

Model: DG-01BS
Power Supply: AC220V/50/60HZ Single Phase
Function:
Wire cutting
Single/Double-end stripping (full or partial)
Double-end twisting
Single/Double-end tinning
Ribbon cable compatibility (customizable)
Wire Processing Range: AWG#32 - AWG#18 (wire diameter 0.6mm-3.2mm)
Productivity: 7000-13000 pcs/hour (depending on wire)
Cutting Length: 10-600mm (customizable)
Cutting Accuracy: 0.2 ® 0.02*L (length)
Stripping Length: 0-7mm (customizable above 7mm)
Twisting Length: 3-7mm
Tin Dipping Length: 0.5-7mm
Air Pressure: 5-6 kg
Machine Size: 1210 x 770 x 1370 mm (without protrusions)
Weight: Approximately 400kg
High-Quality Components:

Servo Motors: Hechuan (6 sets)
Pneumatic Components: SMC (solenoid valve, cylinder, air pipe)
Air Pressure Detection: SMC
Screw Guide: Taiwan HIWIN
Controller: US RAM computer control system
Color Touch Screen: KINCO
Full CNC Debugging: Precise control over parameters like knife size, stripping length, and tinning depth
The DG-01BS Automatic Wire Cut Strip Tin Dip Soldering Machine is a perfect solution for businesses seeking to revolutionize their wire processing operations. Its exceptional efficiency, multi-functionality, precision control, user-friendly design, and focus on a healthy work environment make it a valuable asset for any high-volume production environment.
