Automatic Roll Type Embossing Machines Model YW-AZ -iseef.com
| Price: | US$ 10 / Set |
|---|---|
| Minimum Order: | 1 SET |
| Payment Terms: | T/T OR L/C |
| Port of Export: | NINGBO OR SHANGHAI, CHINA |
Product Details
| Model No.: | YW-AZ | Brand Name: |
|---|
| Certification: | |
|---|---|
| Specification: |
Model: YW-720A-Z / YW-920A-Z / YW-1150A-Z / YW-1300A-Z
Max. embossing speed: 5-60m/min Embossing width: 680mm / 870mm / 1100mm / 1250mm Material available: Paper, Plastic Operation pressure: 2-10Mpa Heating temperature: ≤70℃ Main motor power: 20kw / 32kw / 34kw / 34kw Air pressure: 0.8Mpa Dimension(L*W*H): 4800*2600*1450mm / 4800*2800*1450mm / 4800*3000*1450mm / 4800*3200*1450mm Net weight: 4200kgs / 5200kgs / 6200kgs / 7000kgs |
Packaging & Delivery
| Packaging: | Standard export package |
|---|---|
| Delivery/Lead Time: | 25-50 DAYS |
| Production Capacity: |
Product Description
Automatic Roll Embossing Machine model YW-AZ is automatic equipment with mechanical, electrical and hydraulic system. It is suitable for embossing all kinds of paper and plastic film rolls into exquisite design. It adopts automatic hydraulic lifting system, automatic heating and cooling system, frequency converter to control speed, automatic tension control system and automatic hydraulic system etc.
Main configuration:
PLC control, HMI
Two heating rollers
The front and the back air shaft with automatic hydraulic lift
Pneumatic roller
Frequency converter control
Rectification system
Big hydraulic cylinder
Designed roller
Wool roller
Reducer
Tension control magnetic motor
|
