Arc-quenching tubing/ Arc-quenching fuse tube liner/ Compound tubing fuse tubes
| Price: | US$ 1 |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | L/C,D/P,D/A... |
| Port of Export: | TIANJIN PORT |
Product Details
| Model No.: | 1 | Brand Name: | 1 |
|---|
| Certification: | ISO 9001 |
|---|---|
| Specification: |
Epoxy fiberglass vulcanized fiber combination tube is made by overwrapping vulcanized fiber tube with epoxy resin saturated fiberglass filaments. The angle of filament winding is usually set at 55®. Vulcanized fiber tube becomes an integral tube liner which provides gas-generating and arc-quenching characteristics. Epoxy resin saturated fiberglass provides strength and water resistance. The combination tube is usually coated with UV resistant paint in gray color. Fiberglass/vulcanized fiber combination tube has the following advantages over fiberglass/polymeric synthetics combination tube: no-spark generating, char layer forming to prevent liner from excessive ablation, and the optimum amount of arc-quenching gas generating. The main application of fiberglass/vulcanized fiber combination tube is used in expulsion fuse tube cutout for interrupting high voltage AC circuits during power surge. |
Packaging & Delivery
| Packaging: | 1 |
|---|---|
| Delivery/Lead Time: | 25 |
| Production Capacity: | 10000 |
Product Description
Epoxy fiberglass vulcanized fiber combination tube is made by overwrapping vulcanized fiber tube with epoxy resin saturated fiberglass filaments. The angle of filament winding is usually set at 55®. Vulcanized fiber tube becomes an integral tube liner which provides gas-generating and arc-quenching characteristics. Epoxy resin saturated fiberglass provides strength and water resistance. The combination tube is usually coated with UV resistant paint in gray color.
Fiberglass/vulcanized fiber combination tube has the following advantages over fiberglass/polymeric synthetics combination tube: no-spark generating, char layer forming to prevent liner from excessive ablation, and the optimum amount of arc-quenching gas generating. The main application of fiberglass/vulcanized fiber combination tube is used in expulsion fuse tube cutout for interrupting high voltage AC circuits during power surge.
|
