Anticorrosive Ceramic Lined Ball Valve for chemical industry
| Price: | US$ 800 / Piece |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | TT,LC |
| Port of Export: | Shanghai |
Product Details
| Model No.: | FRQ641TC | Brand Name: | FREE-VALVE |
|---|
| Certification: | 12 month |
|---|---|
| Specification: |
The standards of flange ends ASME B16.5,GB/T9113
Nominal Pressure 1.0MPa,Class150 Size Range DN50~DN 200, NPS2 ~NPS8 Connection type Flange Working Temperature ≤200℃ Operating Type Manual, Pneumatic and Electric Sealing surface material Engineering ceramic Pressure test GB/T13927, API598 Face to Face GB/T12221, API609 |
Packaging & Delivery
| Packaging: | wooden box |
|---|---|
| Delivery/Lead Time: | FOB,CIF,FCA, TT,LC, delivery time:30days |
| Production Capacity: | 200 set/month |
Product Description
FREE-Valve’s Anticorrosive Ceramic Lined Ball Valves are designed with engineering ceramics the engineering ceramics internal parts provide excellent wear resistance, the ceramic ball valves are widely used as an open and close function as well as a throttling control tasks in corrosive medium with abrasive solids content.
Features:
1.The hardness of the ceramic material can be higher than HRC80.
2.Engineering internal parts of ceramic ball valve provide superior protection from corrosive and abrasive medium.
3.Customized actuation types are installed on the ceramic ball valve, the manual lever or gear box, as well as with pneumatic, electric and hydraulic actuators
4.Customized V type ceramic control valve is also available.
5.The valve has a floating ball design, the ball is floating, the ball has a defined clearance and is pressed against the downstream seat under the differential pressure to achieve sealing.
Application
FREE- Valve’s Anticorrosive Ceramic Lined Ball Valves are suitable for Silicon Powder, Alumina Powder, Dry Coal Powder, Limestone Slurry, Gypsum Slurry, Plaster, Fly Ash, Mining Ore, Coal Powder Injection, Metallurgical dust, Thermal Power plant FGD , LiCoO2 powder equipment.
Price terms:FOB,CIF,FCA,CFR
Origin:China
Wechat ID:FreeValve
|
