Anesthesia Multi-Gas Detector

Our anesthetic gas detector can simultaneously measure the concentration waveform and data of CO2, N2O, anesthetic gas, as well as respiratory rate. The types of anesthetic gases measured include halothane, enflurane, isoflurane, sevoflurane and desflurane. The user can manually select the type of anesthetic gas.

Types of Waste Anesthetic Gas Monitoring Detectors
Anesthesia Multi-Gas Detector AneSure™-M
Mainstream Anesthesia Multi-Gas Module, simultaneously measure the concentration waveform and data of carbon dioxide, nitrous oxide and anesthetic gas, as well as respiratory rate.

Anesthesia Multi-gas Detector AneSure™-S
Side stream Anesthesia Multi-Gas sensor, can simultaneously measure the concentration waveform and data of CO2, N2O, anesthetic gas, as well as respiratory rate.

Features of Anesthesia Multi-gas Detector/Module
1.Compatible with a variety of protocols, so that the products can be quickly upgraded and assembled.

2. Plug and play, the host does not need internal circuit, just a serial port. Can measure data within 4 seconds after power on. Suitable for adults, children and newborns.

3. Can also be used in heavy humidity environment for a long time, reducing the cost of use.

4. Automatic pressure compensation. There is a built-in atmospheric pressure sensor, which is suitable for various altitude ranges.

5. High-precision. Careful selection of infrared devices, hardware design and software algorithm, to achieve high signal-to-noise ratio, to ensure the measurement accuracy for temperature range of - 5-50 ®C and in the range of 0 - 20%.

Benefits of Anesthesia Multi-gas Detector/Module

Mainstream and sidestream modes

Compatible with multiple protocols

Plug and Play

Flexible upgrade

Provide you with a one-stop solution for your clinical needs

Excellent performance and reasonable price

Specifications of Anesthesia Multi-gas Detector/Module
Temperature -5~50℃
Relative humidity 10-90%（Non-condensing）
Atmospheric pressure 55-115kpa
Power consumption 150ma
Port and protocol RS-232/ Standard E-8-1,38.4 kBaud,10 ms data interval (KM) or Customized according to customers' requirements
Co2 Measuring Range 0~150mmHg
Accuracy 0~40mmHg, inaccuracy≤¯ 2mmHg；
41~70mmHg, inaccuracy≤¯5% of Reading；
70~100mmHg, inaccuracy≤¯ 8% of Reading；
101~150mmHg, inaccuracy≤¯10% of Reading；
N₂O Measuring range 0~100%
Inaccuracy¯（2vol%+ 2% of Reading）
HAL, ENF, ISO
HAL, ENF, ISO Measuring range 0-12%
Inaccuracy
For 0~8%, ¯（0,2 vol% + 5% of Reading）
For 8~12% Unspecified
SEV Measuring range 0~15%
Inaccuracy
For 0~10%，¯（0,2 vol%+5% of reading）
For 10~15% unspecified
DES Measuring range 0~25%；
Inaccuracy
For 0~18%，¯（0,2 vol%+5% of reading）
For 18~25% unspecified
Respiration Rate Range 2~150 t/min
Inaccuracy the bigger value of ¯1% or 1t/min

If you want to know more details of how often should waste anesthetic gas monitoring be performed, please visit our website.

Now the price of etco2 capnography machine is reasonable, if you have needs, please leave us a message.
