API 600 C5 Gate Valve,10 Inch, 300LB,Hand wheel
| Price: | US$ 100 |
|---|---|
| Minimum Order: | 1PC |
| Payment Terms: | T/T |
| Port of Export: | shanghai |
Product Details
| Model No.: | Z41 | Brand Name: | STV |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: | China API 600 C5 Gate Valve Manufacture,Stv Provide API 600 C5 Gate Valve,10 Inch, 300LB,Hand wheel |
Packaging & Delivery
| Packaging: | WOODCASE |
|---|---|
| Delivery/Lead Time: | 30DAYS |
| Production Capacity: | 1000PCS |
Product Description
Product Detail Design standard:API 600
Body material: C5.
Nominal diameter: 10" (DN300).
Pressure: 300 LB (PN25).
End connection: RF.
Face to face: ANSI B16.10.
Working temperature: -29℃~+560℃.
Test and inspection: API 598.
Product Range
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2"~24" (DN15~DN600).
End connection: BW, Flanged.
Pressure range: 150 LBs~2500 LBs (PN16~PN420).
Operation: Handwheel, Gearbox, Electric, Pneumatic.
Working temperature: -29℃~+560℃.
