ACCTEK Jinan hot sale 1325 fiber laser cutting machine for metal steel

1. Machine features of metal fiber cutting machine:


1). High performance.fiber transmission can make sure the same quality cutting effect in every point of the material.

2). High efficiency,fast cutting speed.photoelectric conversion rate about 35%.

3). Low gas consumption.it has the cutting technology specially for steel board and produce no gas when cutting .

4). Low power consumption .environment -friendly and energy -saving,reduce 20%-30% power compard with co2 cutting machine.

5). Maintenance-free ,fiber transmision without reflection lens,can save time in light path adjustment

fiber exerts its features better in thin metal sheet cutting.

Model AKJ1325F-2
Working area 1300*2500mm
Control System Au3tech
Laser head Au3tech cutting head
Guide rail Taiwan HIWIN linear guide rail 25mm
Transmission Rack and pinion transmission
Reducer French MOTOVARIO reducer
Motor Delta servo motor and drivers 750w
Max Cutting Speed 35m/min
X axis max speed 65m/min
Y axis max speed 100m/min
Z axis max speed 30m/min
X axis max acceleration 1G
Y axis max acceleration 1G
Cooling Way Water chiller
Min line width 0.1mm
Power Requirements 380V, 50/60Hz
Continuous Working Time 24Hours
