ABB 3HNP00043-1 SERVO MOTOR

ABB 3HNP00043-1 SERVO MOTOR
ABB 3HNP00043-1 SERVO MOTOR
ABB 3HNP00043-1 SERVO MOTOR
This function is more or less the backup for the primary load shedding function, which is described int o chapter
3.2. When the primary load shedding fails due to wrong inputs, this function will shed the loads. Frequency load
shedding not only takes the absolute frequency limits into account, but also calculates the df/dt. This gives a
more accurate load shedding. The frequency limits are read in from frequency relays by digital inputs in the
Advant Controlle

Manual Load Shedding
The operator can issue a plant-wide shed priority. To assist the operator in assessing how much load will be
shed if the operator issues a manual load shedding priority, in the main load shedding process display an
accumulated priority load table for the total actual plant load per priority is presented.
Maximum Peak Power Demand Shedding
Some priorities are shed as soon as the power taken from the public grid is tending to supersede the maximum
allowed amount when the in -house generation is maximised. This import maximum is based on periodically
power demand. In this case, the operator can deactivate the mechanism, and also determ ine up and until
which priorities may be shed automatically by this function. Certain priorities can be inhibit from maximum
peak power shed. Before the shed command, an audible alarm is created. So an action can be taken, if there is
time, to overcome the situation.
