7205CDB Angular Contact Ball Bearing 25*52*30mm Chrome Steel GCR15
| Price: | US$ 50 / Piece |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | T/T L/C |
| Port of Export: | Dalian |
Product Details
| Model No.: | 7205CDB | Brand Name: | SUNBEARING |
|---|
| Certification: | ISO9001:2008 |
|---|---|
| Specification: | Single row angular contact ball bearing(70,72,73,718,719 series) |
Packaging & Delivery
| Packaging: | According to customer requirements |
|---|---|
| Delivery/Lead Time: | 2-4 week |
| Production Capacity: | 2000 |
Product Description
Product Description
Angular Contact Ball Bearing 7205CDB
Specification
Design Units
Metric
Structure
Ball Bearing
Weights
0.27kgs
Cage Material
Steel cage
Material
Chrome Steel GCR15
Ball Type
Carbon chromium steel
Seals Type
ZZ
Certificate
ISO9001:2008
Advantage
Single row angular contact ball bearing(70,72,73,718,719 series)
Number of Row
Single
Dimensions
d-Bore Diameter
25mm
D-Outer Diameter
52mm
Precision Rating
P5 P6 P4 P2 P0
Clearance
C2 C3 C4 C5 C0
H-Total Width
30mm
Basic Load Ratings
Cr Dynamic Load Rating
27000N
C0r Static Load Rating
20400N
1.Specifications :
The construction of this ball bearing is similar to mounting two single row angular ball bearings back to back(DB).
Capacities of double row ball bearing is less than single row since few balls can be inserted per row.
This bearing type can sustain radial, moment and bi-directional axial loads.
2.Features :
Angular contact ball bearings have raceways in the inner and outer rings that are displaced with respect to each other in the direction of the bearing axis. This means that they are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.
Our company produce angular contact ball bearings in a wide variety of designs and sizes:
1. single row angular contact ball bearing(70,72,73,718,719 series)
2. double row angular contact ball bearing(32,33 series)
3. four-point contact ball bearing(Q,QJ)
Our bearings are widely used in machine tools, metallurgy, aviation, automobile, railways and other
|
