6211 Deep Groove Ball Bearing 55*100*21mm SUNBEARING

Product Description

Deep Groove Ball Bearing 6211

Specification

Design Units

Metric

Structure

Ball Bearing

Weights

0.619kgs

Cage Material

Steel Cage.Brass Cage.Nylon Cage

Material

Chrome Steel GCR15

Ball Type

Steel Ball

Seals Type

Metal cover seal

Certificate

ISO9001:2008

Feature

Higher rotating precision

Number of Row

Single

Dimensions

d-Bore Diameter

500mm

D-Outer Diameter

100mm

Precision Rating

P0 P5 P4 P6 P2

Clearance



C2 C3 C4 C5 C0

H-Total Width

21mm

Basic Load Ratings

Cr Dynamic Load Rating

43500N

C0r Static Load Rating

29300N



Product Feature



1.The most representative of the rolling bearings, widely used
2.Outer ring with a ring or flange bearing, that is easy to axial positioning and easy to install the shell;
3.The maximum load bearing size is the same as the standard bearing, but the inner and outer rings have a trough, which increases the number of balls and improves the rated load.


Deep Groove Ball Bearing 62 Series Sizes:

This close clearance labyrinth seal retains the lubricant and prevents the entrance of foreign matter. Sealed bearings incorporate steel reinforced rubber seals securely fastened to a groove on the outer ring. Contact with the inner ring is by sealing lip (Contact Suffix LLU). Or, non-contact with the inner ring is by labyrinth seal (Non-contact Suffix LLB) to provide positive sealing at all times.Products are widely used in machinery and equipment, electric power, steel, metallurgy, petroleum,chemical engineering, machine tool, spinning, car, electrical machine, precise instrument,mining machinery, construction machinery, engineering machinery, railway and so on.



Application



Deep groove ball bearings can be used for gearboxes, instruments, motors, household appliances, internal combustion engines, traffic vehicles, agricultural machinery, construction machinery, roller skates, etc.
