6051 Kapton (polyimide) film
| Price: | US$ 40 / Kilogram |
|---|---|
| Minimum Order: | |
| Payment Terms: | FOB |
| Port of Export: |
Product Details
| Model No.: | Brand Name: |
|---|
| Certification: | |
|---|---|
| Specification: |
1. Features: 特性
Smooth and bright film surface without folding, broken, particulate air bubble, the defects of pinpoint and foreign impurities, tidy edges and non damage. 2. Application 应用 Mainly used in electrical and electric insulation application: 1) Formed coil insulation 2) Substrates for FPC 3) Motor solt liner 4) Magnet wire insulator 5) Transformer and capacitor insulation 6) Magnetic and PSA tape 7) Tubing 3. Polyimide film Tech Data Sheet 性能表 No. Item Normal Result 1 Normal Thickness(um) 50¯6 51 2 Density (kg/m3 ) 1.400×103¯0.02 1.400×103 3 Tensile strength(MPa) MD ≥135 182 TD ≥115 160 4 Elongation at break (%) MD ≥35 84 TD 94 5 Contraction Rate (Longitudunal and Horizontal ) (%) 150℃ 0 0 400℃ ≤1.0 0.8 6 Dielectric Strength (V/um) Average Value ≥150 248 Least Value ≥100 220 7 Surface Resistivity ,200℃ ( Ω） ≥1.0×1013 8.1×1014 8 Volume Resistivity ,200℃ ( Ω.M） ≥3.1×1010 3.1×1010 9 Dielectric Constant 48-62Hz 3.5¯0.4 3.5 10 Dissipation Factor 48-62Hz ≤4.0×10-3 1.8×10-3 11 Long-term Heat-Resistance Temperature (℃) ≥180 ≥180 6051 Kapton (polyimide) film Standard No.: JB/T2726-1996 Normal Thickness: Normal Thickness Area Factor Type um mil m2/kg kg/m2 6051 PI Film Series 100JY 25.4 1 28.57 0.035 150JY 40 1.575 18.14 0.0551 200JY 50.8 2 14.29 0.07 300JY 76.2 3 9.52 0.105 400JY 101.6 4 7.14 0.140 500JY 127 5 5.71 0.175 700JY 175 7 4.08 0.245 Width from 5mm up to 1m could be cut by customer’s requirement. For more information on Polyimide Film or other high performance materials, Please contact your representative. |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | |
| Production Capacity: |
Product Description
Polyimide film possesses a unique combination of properties that make it ideal for a variety of applications in many different industries The ability of PI film to maintain its excellent physical, electrical and mechanical properties over a wide temperature range has opened new design and application areas to plastic films.
1. Application 应用
1) Formed coil insulation
2) Motor slot liner
3) Magnet wire insulator
4) Transformer and capacitor insulation
5) PTC insulation
6) Magnetic and PSA tape
7) Tubing
2. Main tech data 性能表
NO. Item Unit Value
1 Normal Thickness um 25 50 75 100 125 175
2 Density g/cm3 1.4¯0.02
3 Tensile MD Mpa ≥175 ≥170 ≥155 ≥150 ≥135 ≥130
Srength TD ≥170 ≥165 ≥140 ≥130 ≥110 ≥100
4 Ultimate Elongation % ≥60 ≥70
5 Shrinkage 30min at 150℃ % 0.15
30min at 400℃ 2 1.9 1.8
6 Dielectric Strength V/um ≥185 ≥165 ≥150 ≥125 ≥120 ≥110
7 *Surface Resistivity ,200℃ Ω ≥1.0×1013
8 *Volume Resistivity ,200℃ Ω.M ≥1.0×1010
9 *Dielectric Constant 48-62Hz 3.5¯0.4
10 *Dissipation Factor 48-62Hz ≤4.0×10-3
11 *Long-term Heat-Resistance ℃ 180
Temperature
12 Thickness tolerance % ¯10
Note: The items marked * are the inherent properties of polyimide film, which are not showed on the testing report for outgoing factory.
Product Supply 供货能力
1. Width: 5~1020mm could be tailored.
2. Core ID: 40, 50, 76 mm Roll OD: 200~250mm
3. Package:
1) Inside: Polythene film
2) Outside: Carton or wooden case
4. Payment: T/T with 50% deposit, Balance payment after your buyers inspection but before shipment.
5. Delivery time: 14 days after receiving your deposit.
6. MOQ: 200kgs which can mix items.
|
