5t Trolley Electric Locomotive for Underground Mining Tunnel
| Price: | US$ 10000 / Set |
|---|---|
| Minimum Order: | 1 set |
| Payment Terms: | L/C, T/T, Western Union |
| Port of Export: | Guangzhou |
Product Details
| Model No.: | CJY5 | Brand Name: | YUTONG |
|---|
| Certification: | ISO9001 |
|---|---|
| Specification: |
Adhesive / total weight (t) : 5 ton Track gauge (mm) : 500.600,762 or 900 Traction (KN) : 6.1kN/ 5.74kN Max. Traction (KN) : 7.36kN Speed(km/h) : 10.6km/h/ 7.5km/h Voltage : 250 Power (KW) : 7.5KW*2 Dimensions Length(mm) : 2700mm/ 2750mm Width(mm) : 940,1082 or 1220mm Height(mm) : 1550 Wheelbase (mm) : 816mm/ 850 mm Wheel diameter (mm) : Φ650mm/ Φ520 mm Min Curve radius (m) : 5.7-6 m Controller : Resistance or IGBT Braking method : Mechanical or Hydraulic Brake |
Packaging & Delivery
| Packaging: | 1 set per wooden box |
|---|---|
| Delivery/Lead Time: | In 15 days after payment |
| Production Capacity: | 1000 sets per year |
Product Description
Trolley electric locomotive is a kind of rail transportation traction equipment, powered by transformers and overhead lines. Mainly used in mines where there is no risk of explosion. Because of its special power supply mode, the trolley electric locomotive has no limit on the cruising range. Therefore, it is suitable for long-term and long-distance use. There are also many options in terms of speed regulation and braking methods. Speed control methods include resistance speed control, chopping speed control and frequency conversion speed control. Braking methods include pure mechanical braking, hydraulic braking and compressed air braking. In addition, electric braking can also be selected as an auxiliary braking method. C: Locomotive for coal mining
J: Trolley electric locomotives
Y: Single-end driver's cab
G: Steel wheel,resistor for speed control
GB: Steel wheel,chopping wave for speed control
|
