5axis cnc router machine 3d EPS processing center

The five-axis cnc router is specially used for processing complex curved workpieces. The workpiece can complete complex processing needs in one clamping, and it can adapt to the processing of modern molds such as auto parts and aircraft structural parts. It is good at processing methods such as space surface processing, special-shaped processing, hollow processing, punching, oblique hole, and oblique cutting.
The advantages of the five-axis cnc router AKM1212-5A:
1.0 ®to 360 ® head rotation and 0 ®to ¯110® head tilting ,ensure more function .
2.Italy's Hiteco 10KW spindle is professionally applied to five-axis cnc router machines; it has strong cutting ability and low noise, which can ensure the machine to work for a long time.
3. Original YASKAWA Servo motors & drivers from Japan, ensure the machine’s stronger strength and high accuracy.
4. Japanese THK 30mm linear guide and Germany WMH HERION rack ,all famous brand and high quality choice ,ensure machine with high performance and long working life .
5. Not only can be used for plane engraving and cutting, but also can be applied to surface engraving of different objects, arc milling, curved surface processing, such as special-shaped artworks, curved doors or cabinet panels, etc.
6. Extra heavy duty steel frame and gantry for maximum straightness and rigidity .
The whole machine is made of welded steel structure. After aging treatment, it does not deform in long-term use. In order to facilitate transportation and hoisting, the base and beam adopt split structure
7. The movable structure of the working table is flexible in operation, ensuring high precision and low vibration.
8. Disc type automatic tool changer, the tool magazine is fixed on the side of the gantry, always at the same horizontal line as the spindle, and the tool is automatically changed, which saves manual tool change time and is more efficient.
9. Equipped with HERO-TECH industrial chiller to cool the main shaft, wear and aging of house bearings, and prolong the service life of the machine tool.
Please note: add distilled water or purified water, do not add tap water.
Applicable industries of five-axis engraving machine AKM1212-5A:
1.Mold industry: wooden ship model, car model, wooden model aviation and many other wooden model.
2.Foam industry: can carve and cut on any kind of foam with 2D and 3D dimension processing.Processing effect: Engraving, cutting, milling, drilling, relief, shadow etc.
3.Sculpture various large non-metallic mold can be particularly suitable for any kind of Foam (EPS) mould, wooden ship model,wooden model aviation and other wooden mould 3D processing: cylinder, square sculpture and so on.
4. Wood Furniture Industry: Wave Plate, fine pattern, antique furniture, wooden
door, screen, craft sash, composite gates,cup board doors, interior doors, sofa legs,
headboards ,game cabinets, computer tables, sewing machines table, instruments etc.
5.Porcelain bathroom industry: gypsum,ceramic,marble cutting or prototyping.
