500T 15 layers plywood hot press machine
| Price: | US$ 38900 / Set |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | telegraphic transfer |
| Port of Export: | QINGDAO |
Product Details
| Model No.: | GLHP500-15 | Brand Name: | GEELONG |
|---|
| Certification: | CE |
|---|---|
| Specification: |
Normal pressure: 500T
Direction of boards inlet: transverse Layers:15 Opening distance:70mm Quantity of hot platens: 16 Size of hot platen: 1370x2700x42mm Hot platen inside pipeline: two inlets and two outlets Quantity of cylinders: 2pcs Diameter of main cylinders:360mm Working stroke of cylinders: 1050mm Allowed pressure: <=25Mpa Closing time of no-loading:15-18seconds Flow of low pressure pump: 250x2pcs Allowed pressure: 3Mpa Power motor: 15kwx2sets Flow of high pressure pump: 25x1pcs Allowed pressure: 25Mpa Power of motor: 7.5kwx1set Dimension: 3700x1370x4960mm Controlling methods: automatic hydraulic stations Hydraulic station brand:WUXI brand Thickness of up and down column: 900mm Main steel plate thickness: 35mm Total weight of this machine: 33-34T Heating medium: thermal oil Controller electrical parts: Delta, Schneider,Siemens PLC,Siemens touching screen |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | 20 days |
| Production Capacity: | 2CBM per hour |
Product Description
Plywood hot press is one of the main equipment in the plywood production process. It is the equipment for hot pressing of the board slab after the glue combination. The different types of plywood has different requirements on the performance of the press: ordinary plywood, aero plywood, plastic panel, wood laminated plastic board and ship plywood are required to increase the pressure in turn. Plywood hot press consists of three parts: the hot press main machine, the control drive part (hydraulic system and electric control system), and the heating system.
|
