450 Ton Double Truss Type Mrt Launching Girder
Price: | US$ 300,000 - 800,000 / Set |
---|---|
Minimum Order: | 1 Set/Sets |
Payment Terms: | T/T, L/C, T/T+L/C |
Port of Export: | Qingdao, Tianjin or Shanghai, China |
Product Details
Model No.: | LG | Brand Name: | Huada Heavy Industry |
---|
Certification: | ISO CE SGS GOST |
---|---|
Specification: |
Feature:Gantry Crane Condition:New Application:for bridge erection Rated Loading Capacity: 450 ton Rated Lifting Moment: 4500 Kn Max. Lifting Load: 450 ton Max. Lifting Height: 60 m Span: 30 m to 50 m Place of Origin: Henan, China (Mainland) Warranty:18 months After-sales Service Provided:Engineers available to service machinery overseas Wind alram system:Yes Safety device:Included Voltage lower protection:Yes Working duty: A3 applied angle:45ª adaptive cross slope:2.50% Maximum longitudinal slope:≤7% Maximum Transverse slope:≤5% Erection method:span by span |
Packaging & Delivery
Packaging: | main beams are packaged by plastic woven cloth for launching gantry. |
---|---|
Delivery/Lead Time: | 45 days after receiving the deposit |
Production Capacity: | 50 Set/Sets per Month |
Product Description
Product Description 450 ton double truss type concrete MRT launching girder is generally used in the erection of the Highway Bridge and Subway Bridge, using the precast segmental prestress concrete box beam (PC beam) assembly. The main feature is the high efficiency of construction and self-traveling. Generally it is composed of the main beam, leg and winch trolley, the main girder is used for bearing, the leg is to execute machine transverse moving, longitudinal moving, leveling, support, cross span, cross scale and other functions, and the winch trolley used for lifting the precast girder.
Packing & Delivery
Packing
1. Electric parts are packed by high quality plywood crate, to reduce distortion in conveying;
2. Main beams, end beams and electric hoist are packed by plastic woven cloth. It can reduce abrasion when transport.
Delivery
1.If the size of 450 ton double truss type concrete MRT launching girder are suitable for container ship, usually by container;
2.If the size is too big, usually by bulk ship or by container after truncation; Transport ways are based on reducing cost for you and keep the crane performance.
Delivery time
Within 30 to 40 working days after the receipt of deposit.
Transportation
Generally 35 days to 50 days to destination port.
FAQ
1.What's the information should I provide when inquiry about the 450 ton double truss type concrete MRT launching girder?
a .we need the Bridge Drawing;the Maximum longitudinal slope and the Maximum Transverse slope;
b. The Girder/beam drawing;
2.How many Personnel and equipment to assemble launching gantry in the worksite we need?
Personnel: 8 to 10 workers equipment
Truck crane>50 t :2 sets
Φ19.5 steel wire rope 8 m: 4 ropes
Sleepers:several
Electric welding machine: 1 set
Oxygen, acetylene:1 set
Hammer(12 pound and 8 pound):1 set for each
Wrench and pincher: several
Gradienter: 1 set
3.What are inspection standard for load test of 450 ton double truss type concrete MRT launching girder?
a. Dynamic load test
1.1 times rated load, main girder does not down deflection, all mechanisms work well, performance parameters meet the design demand, all limit switches and safety protection interlock devices are reliable, all spare parts does not have cracking and flexible connection, all motors and contactors are not overhead.
b. Static load test
1.25 times rated load, all mechanisms work well, the crane stops 20 min to 30 min as trial load is lifted 10 cm high, then measure main girder down deflection(theodolite, ruler). Put down trial load to measure main girder upper camber, repeat 3 times, steel structure does not have permanent deformation.
4.How to make highway bridge concrete girders?
a.Full span prefabrication,
b.Segment girder prefabrication
c. Full span cast in place girder
d. Segment cast in situ
5.How about maintenance of 450 ton double truss type concrete MRT launching girder?
a. Lubricating. b. Steel wire rope. c. Spreader. d. Pulley blocke. e. Wheels. f. Brake.
