3kW~12kW rack mounted load bank for data center

RACK MOUNTED LOAD BANK
Function
The rack mounted AC dummy load equipment can fully simulate the power usage, heat dissipation and other air flow changes of the server. Through the use of rack mounted load bank for integration test, the effective operation of power supply and distribution system (including UPS system),air conditioning fresh air system,lightning protection and grounding system,monitoring system,comprehensive environment of computer room, it environment of cabinet and decoration engineering of computer room is ensured, and the design and operation requirements are verified.

Application
1.DC generator set,battery charging board,UPS charging board,photovoltaic combiner box and other DC power supply detection occasions.
2.AC test server,UPS,generator set and other AC power supplies.
3.Output power and load carrying capacity of communication AC equipment such as AC voltage stabilizer, inverter and switching power supply.
4.Simulating resistive load can detect the performance of power supply under different loads.


Rack Mounted Load Bank Specification
Rated voltage: AC230V/customized
Maximum load power: 3~12kW
Load step: Customized
Load accuracy (per step): ¯2%
Connection mode:
1,single power source,three input,independent control power input
2,dual power source,six input,manual/auto control
Control power source: AC220V/50/60Hz/customized
Insulation class: F
Working mode: continuous work/cutomized
Cooling mode: forced air cooling,horizontal discharge
Control mode: MCB(ABB/Schneider brand)
Color/Style: blue/yellow/customized
Ambient temperature:-20℃to 50℃
Humidity: up to 100%
Altitude: Up to 2500m
Atmospheric pressure: 86 to 106kPa
Dimension: reference following table
Function options:
1,over temperature alert
2,CFM display
3,air volume adjustable
4,single/dual power source selectable
5,power line length selectable
6,cabinet style/color adjustable
