3 tons diesel forklift trucks with CE
| Price: | US$ 8000 / Set |
|---|---|
| Minimum Order: | 1set |
| Payment Terms: | 30% TT as deposit, balanced before shippment |
| Port of Export: | Shanghai |
Product Details
| Model No.: | FD30 | Brand Name: | Saferlifts |
|---|
| Certification: | CE SGS |
|---|---|
| Specification: |
Basic Info Model NO.: FD30 Power: Diesel Emission Standard: Euro 3 Seats: One Seat Condition: New Mast: 3-6m Trademark: Saferlifts Origin: Shanghai Transmission Type: Automatic Load Capacity: 1-10t Drive Wheel: 2 Storage: in Nude Color: Orange/Yellow/Green/OEM Color Engine: Imported Engine/Chinese Engine Specification: CE, SGS HS Code: 84272090 Product Description Customer Question & Answer Capacity: 3000KG Engine: ISUZU C240 diesel engine Transmission: Automatic Tyre: Pneumatic Wide-view mast, solid overhead guard, Ergonomic adjustable steering wheel and seat. 1. Wide-view mast gives the operator an enhanced forward visibility, which adds greatly to the efficiency and safety of operator. 2. Specially designed solid over-head guard provides additional security for the operator. 3. Super and non-slip step make operating convenient and safe. 4. The powerful engine ensures GOOSENSE trucks high handing performance and offers an intrinsically safe and efficient operation. 5. This popular feature allows operator to adjust seat to their preferred position of operation comfortable and free. 6. The instruments offer an easy access to the working condition of the truck, thus makes handling process more efficient and safe. |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | 15 days |
| Production Capacity: | 3000kg |
Product Description
General 1 Model FD30 2 Power Type Diesel
3 Rated Capacity kg 3000
4 Load Centre mm 500
Characteristic& Dimension 5 Lift Height mm 3000
6 Free lift height mm 125
7 Fork Size L× W× T mm 1070× 125× 45
8 Mast Tilt Angle F/R Deg 6® /12®
9 Front Overhang (Wheel center to fork face) mm 487
10 Rear overhang mm 448
11 Ground Clearance
Bottom of mast mm 140
12 Overall Dimension Length to face of fork(Without fork) mm 2670
13 Overall Width mm 1225
14 Mast Lowered Height mm 2065
15 Mast Extended Height(With backrest) mm 4150
16 Overhead Guard Height mm 2090
17 Turning Radius (outside) mm 2415
18 Min. right angle asisle width mm 2120
Performance 19 Speed Travel (No load) km/h 19
20 Lifting (Full load) mm/s 500
21 Lowering(Full load) mm/s 400
22 Max. Drawbar Pull(Full load) kn 13
23 Max. Gradeability (No load/Full load) % 20
Chassis 24 Tire Front mm 28× 9-15-12PR
25 Rear mm 6.50-10-10PR
26 Tread Front mm 1000
27 Rear mm 980
28 Wheelbase mm 1700
29 Service weight kg 4390
Power& Transmission 30 Battery Voltage/Capacity V/Ah 12/90
31 Engine Model C240 PKJ
32 Manufacture ISUZU
33 Rated output/r. p. m. kw 34.5/2500
34 Rated torque/r. p. m. N@ m 139/1800
35 No. of Cylinder 4
36 Bore× Stroke mm 86× 102
37 Displacement cc 2369
38 Fuel Tank Capacity L 70
39 Transmission Type Powershift
40 Stage FWD/RVS 1/1
|
