110V220V DC power hanging system battery charger rectifier applicable for system under 38AH/220V
| Price: | US$ 500 / Piece |
|---|---|
| Minimum Order: | 1 |
| Payment Terms: | LC |
| Port of Export: |
Product Details
| Model No.: | 07 | Brand Name: | Tonhe |
|---|
| Certification: | |
|---|---|
| Specification: |
1.AC input:220V¯15% 2.PT voltage:100V¯10%(optional) 3.Power grid frequency:50HZ¯5% 4.Module power factor:≥92%(single rectifier) 5.Output voltage:190V-260V constant adjustment(95V-130V constant adjustment for 110V system) 6.Voltage stabilization accuracy:≤¯0.5% 7.Current stabilization accuracy:≤1% 8.Ripple:≤0.5% 9.Current sharing imbalance for modules in parallel:≤¯3% 10.Over-voltage protection:320V¯15V（160V¯8V for 110V system) 11.Insulation resistance:≥20MΩ 12.Noise:≤50dB 13.Dimension:560*700*300mm(W*H*D) 14:Weight:40KG |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | |
| Production Capacity: |
Product Description
1.AC input:220V¯15% 2.PT voltage:100V¯10%(optional)
3.Power grid frequency:50HZ¯5%
4.Module power factor:≥92%(single rectifier)
5.Output voltage:190V-260V constant adjustment(95V-130V constant adjustment for 110V system)
6.Voltage stabilization accuracy:≤¯0.5%
7.Current stabilization accuracy:≤1%
8.Ripple:≤0.5%
9.Current sharing imbalance for modules in parallel:≤¯3%
10.Over-voltage protection:320V¯15V（160V¯8V for 110V system)
11.Insulation resistance:≥20MΩ
12.Noise:≤50dB
13.Dimension:560*700*300mm(W*H*D)
14:Weight:40KG
|
SUPPLIER PROFILE
|
|||
|---|---|---|---|
| Company: | Shijiazhuang Tonhe Electronics Technologies Co.,Ltd | ||
| City/State | Shijiazhuang, Hebei | Country: |
China
|
| Business Type: | Export - Manufacturer / Trading Company | Established: | 1998 |
| Member Since: | 2019 | Contact Person | Chen wei |
