1- 80t europe standard wire rope electric hoist
| Price: | US$ 500 |
|---|---|
| Minimum Order: | 1 Piece |
| Payment Terms: | T/T |
| Port of Export: | Tianjin port Shanghai port |
Product Details
| Model No.: | ND | Brand Name: | Nucleon |
|---|
| Certification: | ISO CE |
|---|---|
| Specification: |
1. Capacity from 1ton to 20ton;
2. Standard lifting height are 6m, 9m and 12m; 3. Lifting speed is double speed or frequency inverter control; 4. Traveling speed is controlled by frequency inverter. 5. Working duty class are FEM 2m, 3m or ISO M5, M6; 6. Working environment temperature: -25~+42 certigrade; 7. Working elevation: within 1000m; 8. Low working noise; |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | 30days |
| Production Capacity: | 1ton~20ton |
Product Description
Introductions
This wire rope electric hoist in combination of light flexible beam crane and swing-jib crane will better exert its advantages of lightweight and flexibility, fully realize the solutions to three-dimensional material handling and meet customer requirements for process layout, greatly improving production efficiency.
Technical parameters
1 Motor
Winding: 2-speed – 8/2 poles
Duty Cycle: Intermittent S3
Isolation Class: F
Protection: IP55
2 Chain Guide
Design: The upper chain guide is wear resistant plastic, the lower one steel.
3 Gearbox
Design: 3-stages, helical gearbox in flat design. Therefore especially low noise.
Gears: All gearteeth are ground or milled and heat treated.
4 Housing
Design: Low weight due to aluminum alloy.
Motor cover is shock-resistant plastic.
5 Safety Clutch
Design: Operates in oil bath with minimal resistance force variations.
Adjustment: Set at factory at 1.3 to 1.4 times rated load.
Life Expectancy: Minimum life expectancy of 800 operating hours at FEM 1Am duty cycle.
Adjustment free for approximately 20,000 slip cycles at an average activation time of 1,5 sec.
|
