0.35T Fixed Point Casting Furnace

The fixed-point casting intermediate frequency furnace belongs to a new type of professional furnace, which is designed and manufactured by foreign technology and has the international advanced level. The unique hydraulic tilting rod linkage mechanism can always pour the metal solution into the small diameter receiving port during the whole process of melting the molten metal. It is the preferred equipment for producing metal powder and similar process requirements using water (gas) atomization process.
Advantage:
1. The fixed-point pouring medium-frequency melting furnace has a good electromagnetic stirring effect, which is beneficial to the smelting of metal temperature and uniformity of the structure, which is beneficial to scumming and reducing impurities;
2, the frequency range is wide, from 1KHZ to 20KHZ, can comprehensively consider the amount of melting, electromagnetic stirring, heating efficiency, noise during operation and other factors to design the induction coil and matching compensation capacitor to determine the output frequency;
3. Fixed-point pouring medium-frequency electric furnace is small in size and light in weight. The melting capacity ranges from a few kilograms to several hundred kilograms. It can be used in a wide range of applications. It is suitable for factory production and is also suitable for small-scale smelting in schools and research institutes.

Equipment Components:
Ordinary classic type one electric furnace, one aluminum shell furnace body, one 350kw parallel inverter power supply, one set of inverter compensation capacitor, the power supply structure is 3-phase 6-pulse single-rectification parallel inverter structure, and the control part adopts PLC smelting management System, PLC-assisted smelting management system, not only can display real-time data and information of power supply operation, but also display the operating status and information of the whole system, and has automatic oven, cold furnace start, fault diagnosis, fault information display and storage, operation Information display, system status display and other functions.
Application :
The fixed-point pouring intermediate frequency furnace is mainly used for the melting of steel, stainless steel, copper, aluminum, gold, silver and other materials. The melting range can be selected in a wide range, which is suitable for factory production and is also suitable for small-scale melting in schools and research institutes.
