multi core flexible H07RN-F rubber cable
Price: | US$ 1.4 |
---|---|
Minimum Order: | 100meters |
Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
Port of Export: | Qingdao/ Tianjin or as your request |
Product Details
Model No.: | Brand Name: | Huadong cable |
---|
Certification: | |
---|---|
Specification: | Voltage:450V/750VConductor:Copper To IEC 60228 Class 5 & VDE 0295 Class 5Insulation:Rubber/ Sheat:olychloropreneCores:Multi-CoreStandard:IEC/VED/DIN/ASTM etc.Packaging:Iron or Wooden Drum |
Packaging & Delivery
Packaging: | Iron Or Wooden Drum |
---|---|
Delivery/Lead Time: | |
Production Capacity: | 200000 Kilometer/Kilometers per Month |
Product Description
H07RN-F rubber cable feature: H07RN-F is a harmonized, heavy duty and flexible chloroprene sheathed cable; Voltage Rating:Working: 450/750V, Test: 3000V. Temperature Rating:-25®C to +60®C,Static:+85®C; Bending Radius: Flexing: 15 x cable diameter;Conductor Stranding:IEC 60228 Class 5 & VDE 0295 Class 5 Static: 6 x cable diameter,Current Rating:H07RN-F Refer to IEE Regs Table 4F1A&B;
H07RN-F rubber cable Description:
Used extensively for trailing and flexible supply leads in either single or multicore versions, these H07RN-F rubber cables remain flexible even at sub-zero temperatures.
H07RN-F rubber cables use neoprene (PCP) for its sheath. The improved abrasion resistance and the ability to withstand many oils and chemicals make the neoprene sheathed H07RN-F cables suitable for the most arduous conditions.
1. Construction: Fine copper wire strands to IEC 60228 class 5. Rubber insulation colour coded to BS 7671/HD 308 S2 (cables with over 5 cores, A07RN-F, are number coded). Cores twisted together. Black neoprene (PCP) outer sheath to BS 7919:2001 table 14.
2. Application range
• Handheld and power supply devices according to HD 516/VDE 0298-300 • According to HD 516/VDE 0298-300:... tools, machinery and agricultural devices for medium mechanical stress;for mobile engines and machinery; on plaster; not for submersion except for exceptional, brief flooding (seeH07RN8-F cable for submersible pumps);
3. Benefits
• Heavy-duty, rubber-sheathed cable • High stresses • Permitted up to 1000 V (0.6/1 kV) alternating voltage for protected and fixed installation
• Arrangements made of single-core, rubber-sheathed cables H07RN-F can be used for short circuit-proof and short-to-ground-proof installations in accordance with VDE 0100 Part 520
5.Design • Bare copper wire according to HAR • Core insulation: rubber compound type EI 4 • Outer sheath: rubber compound, type EM2
6. Product features
• Flame-retardant according to IEC 60332-1-2 • Oil-resistant according to EN 60811-2-1
• Normatively not ozone-resistant according to HD 22.4/VDE 0282-4 and HD 22.1/VDE 0282-1
