Mini Size 10mm Anti Metal RFID UHF Tag Alien H3
| Price: | US$ 0.5 |
|---|---|
| Minimum Order: | 100 |
| Payment Terms: | T/T |
| Port of Export: |
Product Details
| Model No.: | OPPD20 | Brand Name: | OPP IOT |
|---|
| Certification: | CE/RoHs |
|---|---|
| Specification: | 20mm |
Packaging & Delivery
| Packaging: | |
|---|---|
| Delivery/Lead Time: | |
| Production Capacity: |
Product Description
Functional Specifications:
RFID Protocol: EPC Class1 Gen2, ISO18000-6C
Frequency: (US) 902-928MHz, (EU) 865-868MHz
IC type: Alien Higgs-3
Memory EPC 96bits (Up to 480bits) , USER 512bits, TID64bits
Write Cycles: 100,000times
Functionality: Read/write
Data Retantion: Up to 50 Years
Applicable Surface: Metal Surfaces
Read Range :
(Fix Reader:ThingMagic FU-M6-E) 320cm - (US) 902-928MHz, on metal
280cm - (EU) 865-868MHz, on metal
240cm - (US) 902-928MHz, on metal
230cm - (EU) 865-868MHz, on metal
Warranty: 1 Year
Physical Specification:
Size: Diameter20mm
Thickness: 2.0mm without IC bump, 2.8mm with IC bump
Material: FR4 (PCB)
Colour: Black(Red, Blue, Green, White)
Mounting Methods
Weight: 1.0g
Environmenal Specification:
IP Rating: IP68
Storage Temperature: -40®С to +150®С
Operation Temperature: -40®С to +100®С
Cerifications: Reach Approved, RoHS Approved, CE Approved
|
